3-5
3
Application examples
Component
storage
1
2
Production
line
(Pitch can be adjusted)
(Pitch can be adjusted)
Pitch setup
Set tapes to feeders according to
setup instructions.
Set feeders to feeder plates one
by one according to setup
instructions.
Set-up station
on machine
Out of components
Setup change
Compare with the board data and
check that there is no problem.
Start mounting
Programming
Prepare feeders and components.
Offline setup
station
Work flow
Example of application using fixed banks
63304-F3-00
n
NOTE
Application methods vary greatly depending on conditions such as the number of optional devices (stations) and
factory layout. The above example should be taken only as a reference for applications.
A-1
F3 FEEDER Specifications
Feeder Name
Feeder Dimensions &
Weight
8mm
Converted
Loading Width
Compatible Carrier Tape Specs.
Compatible
Components
Length Height Width
Weight
(kg)
12mm
pitch
16mm
pitch
Width
(mm)
Max.
Width
(mm)
Material
Max. Embossed
Pocket
Protuberance
Dimension (mm)
Usable Feed Pitches
1 F3 FEEDER ASSY. 8MM 425 226 11.5 0.7 1 1 8 1.0
Paper/
embossed
3 1
(*1)
, 2, 4, 8
Electronic components
packaged in a carrier
tape having the
dimensions shown at
left.
2 F3 FEEDER ASSY. 1216 425 226 23.5 1.2 2 2
12
(for 12mm)
1.0
Paper/
embossed
15
4, 8, 12, 16
(*2)
↑
16
(for 16mm)
0.8 Embossed
3 F3 FEEDER ASSY. 24MM 425 226 31.5 1.35 3 2 24 0.6 Embossed 4, 8, 12, 16, 20, 24
(*2)
↑
4 F3 FEEDER ASSY. 32MM 425 226 39.5 1.5 4 3 32 0.6 Embossed
17
4, 8, 12, 16, 20, 24, 28,
32, 36, 40, 44, 48, 52,
56
(*2)
↑
5 F3 FEEDER ASSY. 44MM 425 226 51.5 1.8 5 4 44 0.6 Embossed
↑
6 F3 FEEDER ASSY. 56MM 425 226 63.5 2.0 6 4 56 0.6 Embossed
↑
7 F3 FEEDER ASSY. 72MM 425 226 79.5 2.4 7 5 72 0.6 Embossed
↑
8 F3 FEEDER ASSY. 88MM 425 226 95.5 2.93 8 6 88 0.6 Embossed
↑
(*1) In order to use components packaged on an 8mm width, 1mm pitch (W8P1) tape, the standard tape guide must be replaced with the following tape guide: KHJ-MC14A-S0x PARTS, TAPE GUIDE P1.
(*2) The following items must be verified when using a 12mm or 16mm width tape with a pitch of 16mm ; a 32mm width tape with a pitch of 36mm or more, or a 44mm or more width tape with a pitch of 44mm
or more:
· Verify that the component can be picked up from the tape guide opening.
· Verify the feeder firmware.
· Verify that the tape runs along the mounter's tape path.
