2-1 2 Replacing parts 1. Replaceable par ts 2. T ape guide assembly 1 1. Handle 13. P/O2 roller 12. P/O lever assembly 5. Under rail 7. T ail pin 6. Clamping lever assembly 14. Board connector 9. Unclamping wire 10. Wire…

100%1 / 86
10. Wire covers 1 and 2 2-20
10.1 Removal 2-20
10.2 Installation 2-21
11. Handle 2-22
11.1 Removal 2-22
11.2 Installation 2-23
12. P/O lever assembly 2-26
12.1 Removal 2-26
12.2 Installation 2-26
13. P/O2 roller 2-27
13.1 Removal 2-27
13.2 Installation 2-28
14. Board connector 2-29
14.1 Removal 2-29
14.2 Installation 2-29
2-1
2
Replacing parts
1. Replaceable parts
2. Tape guide assembly
11. Handle
13. P/O2 roller
12. P/O lever assembly
5. Under rail
7. Tail pin
6. Clamping lever assembly
14. Board connector
9. Unclamping wire
10. Wire cover 1
10. Wire cover 2
8. Under plate
4. Tape guide rear lever
3. Tape guide front lever
Replaceable parts
63201-9L-20
2-2
2
Replacing parts
2. Tape Guide Assembly
2.1 Removal
1
Lift the tape guide assembly.
Open the tape guide front lever and lift the
tape guide assembly.
63202-9L-10
2
Remove the tape guide assembly.
Push down the tape guide rear lever and
remove the tape guide assembly from the
body.
63203-9L-10
Step 1
2
Lifting the tape guide assembly
Tape guide assembly Tape guide front lever
1
Step 2
Removing the tape guide assembly
Tape guide rear lever
Tape guide assembly
2
1
