1-21
1
Handling
8. Daily Inspection and Maintenance
Daily inspection and maintenance are necessary in order to use the tape feeder safely for a long period of
time.
8.1 Daily inspection
Check the following before using the tape feeder.
n
Inspection items
Inspection Items How to solve the problem
Is the clamping lever tight enough? Refer to “6. Clamping lever assembly of Chapter 2”
Is the tape guide assembly tight enough? Refer to “2. Tape guide assembly of Chapter 2”
Are any of the screws loose? Tighten the screws.
Are any of the components deformed or broken? Repair or replace the part.
Are any of the components missing or lost? Repair or replace the part.
c
CAUTION
Check the feeder after removing it from the machine.
1-22
1
Handling
8.2 Precautions for maintenance
c
CAUTION
Never remove the parts shown in the figure below.
· Feeder side cover 1
· EL box cover
· Idle gear cover 1
· Idle gear cover 2
· Splice sensor (if installed)
c
CAUTION
Never touch or grease the part in the figure below.
· Sprocket
Parts in need of attention during maintenance
Idle gear cover 2
Feeder side cover 1
EL box cover
Idle gear cover 1
Sprocket
Splice sensor
63121-9L-10
1-23
1
Handling
8.3 Cleaning the tape guide assembly
If debris or chip components are jammed in the gap between the tape guide assembly and feeder frame, the
tape guide assembly may rise, causing the pickup position to shift. Follow the instructions below to clean the
tape guide.
1
Lift the tape guide assembly.
Open the tape guide front lever and lift the tape guide assembly.
2
Clean.
1. Wipe debris or chip components in the tape guide assembly and on the tape travel surface of the
feeder frame with a cotton swab or the like. Then, clean with an air blow tool.
2. Clean the top tape folding part of the tape guide assembly with a needle or thin wire, etc.
Cleaning the tape guide assembly and the tape travel surface
Tape guide assembly
Tape guide front lever
Top tape folding part
Tape travel surface
63120-9L-20
