Page 1-2 444C-E-OMA01-A01-01 1-1 Names and Mechanism of Each Unit CM201 External view Front view Status indicator (3-color indicator light) Front panel Power supply switch Rear view Feeder table 1 Front cover Rear panel …
Page 1-1
444C-E-OMA01-A01-02
Chapter 1
GENERAL DESCRIPTION
General description
This chapter describes the following.
Names and mechanism of each unit
This describes the names and mechanism of each unit by using illustrations.
Production process
This describes the mounting process in due order.
Specification
This describes the specification of the equipment and available boards.
CM201
CM202
4V4C-AA00
4U4C-AA00
Page 1-2
444C-E-OMA01-A01-01
1-1 Names and Mechanism of Each Unit
CM201 External view
Front view
Status indicator
(3-color indicator light)
Front panel
Power supply switch
Rear view
Feeder table 1
Front cover
Rear panel
Rear cover
Feeder table 2
4V4C-AA00
4V4C-AM00
Page 1-3
GENERAL DESCRIPTION
1
CM202 External view
Front view
Rear view
Status indicator
(3-color indicator light)
Front panel
Power supply switch
Feeder table 3
Front cover
Rear panel
Rear cover
Feeder table 4
Feeder table 1
Feeder table 2
444C-E-OMA01-A01-01
Names and Mechanism of Each Unit
4U4C-AB00
4U4C-AA00
