GENERAL DESCRIPTION
1
CM202 External view
Front view
Rear view
Status indicator
(3-color indicator light)
Front panel
Power supply switch
Feeder table 3
Front cover
Rear panel
Rear cover
Feeder table 4
Feeder table 1
Feeder table 2
444C-E-OMA01-A01-01
Names and Mechanism of Each Unit
4U4C-AB00
4U4C-AA00
Page 1-4
Servo switch
Used for ON/OFF power
switch of servo system motor.
444C-E-OMA01-A01-05
Operating units
Touch panel ( 2-2)
Used to operate the machine.
Emergency stop button
(CM201-D/DU/DH/DS Two in total)
(CM202-D/DU Four in total)
(CM202-DH/DHU/DK/DS Two in total)
( SAFETY PRECAUTIONS)
When you press this button, the
machine comes to an emergent
stop.
Names and Mechanism of Each Unit
Touch panel
Operating panel
Servo switch
(Inside the cover)
443C-101P
Operating panel ( 2-1)
Used to start/stop the
machine and so on.
Floppy disk drive
Used to write and read pro-
gramming data.
Power supply switch
Used for ON/OFF power switch
of machine.
OFF ( )
ON ( )
SERVO
443C-101P
STOP
UNLOCK
STEP
START
LIGHT ON
SELECT
KEY LOCK BACK LIGHT OFF
R
E
L
E
A
S
E
T
R
I
P
O
F
F
O
N
R
E
S
E
T
Front view
4U4C-AA00
Page 1-5
GENERAL DESCRIPTION
1
Status indicator (3-color indicator light)
This light indicates the state of machine. If any trouble occurs during operation, it warns you by a buzzer.
444C-E-OMA01-A01-01
Regulator knob
Used to adjust the supply air pressure.
Names and Mechanism of Each Unit
Stage lamp (CM201: Two in total / CM202: Four in total)
When chips run out or trouble occurs on a stage, its lamp
blinks.
During automatic operation
• Not lit : Running normally
• Lit : Out of chips
• Blinking: Trouble
During teaching
• Lit : Running
444C-109TE
(Inside the cover)
Rear view
Red
Yellow
Green
444C-202P
Regulator
knob
444C-101P
4U4C-AA00
