Head Reconfiguration Kits 1 Montageanleitung Head Reconfiguration Kits SIPLACE X-Serie
Ausgabe 07/2010
9
1 Montageanleitung Head
Reconfiguration Kits SIPLACE X-Serie
1.1 Kopfmodularität
Bei der SIPLACE X bestehen folgende Möglichkeiten der Kopfkonfiguration: 1
1.1.1 X2 Kopfmodularität
X2
Bestückbereich 1 Bestückbereich 2 erst ab SW Version
603 SP1
konfigurierbar
Portal 1 Portal 3
Bestückkopf
C&P20 C&P20
C&P20 C&P12
C&P20 C&P6
C&P20 TH
C&P12 C&P12
C&P12 C&P6
C&P12 TH
C&P6 C&P6
C&P6 TH
TH TH
1 Montageanleitung Head Reconfiguration Kits SIPLACE X-Serie Head Reconfiguration Kits
Ausgabe 07/2010
10
1.1.2 X3 Kopfmodularität
*Für weitere Informationen siehe Kapitel 1.1.4 ”Voraussetzungen und Einschränkungen für Twin Head im 2-Portalbe-
reich”
1
X3
Bestückbereich 1 Bestückbereich 2 erst ab
SW Version
603 SP1
konfigurierbar*
Portal 1 Portal 4 Portal 3
Bestückkopf
C&P20 C&P20 C&P20
C&P20 C&P20 C&P12
C&P20 C&P20 C&P6
C&P20 C&P20 TH
C&P12 C&P12 C&P12
C&P12 C&P12 C&P6
C&P12 C&P12 TH
C&P12 C&P6 C&P6
C&P12 C&P6 TH
C&P12 TH TH X
C&P6 C&P6 C&P6
C&P6 C&P6 TH
C&P6 TH TH X
TH TH TH X
Head Reconfiguration Kits 1 Montageanleitung Head Reconfiguration Kits SIPLACE X-Serie
Ausgabe 07/2010
11
1.1.3 X4 Kopfmodularität
*Für weitere Informationen siehe Kapitel 1.1.4 ”Voraussetzungen und Einschränkungen für Twin Head im 2-Portalbe-
reich”
1
Der Bestückkopf C&P 20 kann nur in Verbindung mit dem BE-Wagen, X-Serien-Einzug und
X-Zuführmodulen verwendet werden. 1
X4
Bestückbereich 1 Bestückbereich 2 erst ab SW
Version 603
SP1
konfigurierbar*
Portal 1 Portal 4 Portal 2 Portal 3
Bestückkopf
C&P20 C&P20 C&P20 C&P20
C&P20 C&P20 C&P12 C&P12
C&P20 C&P20 C&P12 C&P6
C&P20 C&P20 C&P12 TH X
C&P20 C&P20 C&P6 C&P6
C&P20 C&P20 C&P6 TH X
C&P20 C&P20 TH TH X
C&P12 C&P12 C&P12 C&P12
C&P12 C&P12 C&P12 C&P6
C&P12 C&P12 C&P12 TH X
C&P12 C&P12 C&P6 C&P6
C&P12 C&P12 C&P6 TH X
C&P12 C&P12 TH TH X
C&P12 C&P6 C&P12 C&P6
C&P12 C&P6 C&P12 TH X
C&P12 C&P6 C&P6 C&P6
C&P12 C&P6 C&P6 TH X
C&P12 C&P6 TH TH X
C&P12 TH C&P12 TH X
C&P12 TH C&P6 TH X
C&P12 TH TH TH X
C&P6 C&P6 C&P6 C&P6
C&P6 C&P6 C&P6 TH X
C&P6 C&P6 TH TH X
C&P6 TH C&P6 TH X
C&P6 TH TH TH X
TH TH TH TH X
