2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits Head Reconfiguration Kits 07/2010 Edition 252 2 TBS 25 0/10X TBS 250 /20Y DBM/3P-06 5 V / 15A 15V/1 ,7A 15 V/ 1,7A DBM/3P-06 TBS 25 0/10X TBS 2 50 /20Y…
Head Reconfiguration Kits 2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits
07/2010 Edition
251
2
TBS 250/10X
TBS 250 /20Y
DBM/3P-06
5 V / 15A 15V/1,7A 15V/ 1,7A
DBM/3P-06
TBS 250/10X
TBS 250 /20Y
DBM/3P-06
SDS 120/2.5S1-03 (00353445-)
SDS 60 3Z1-02 (03002141-)SDS 60/1D1-02 (03002142-)
DBM/3P-06
15 V / 5A 15 V / 5A
Anti crash board
Gantry
1/2
Gantry
4/3
X
Z X
Z1
Y
dp
X
Star
Dp 1
Z2
SDS 60/1Z1 (00353446-) (f. Segment 2)
SDS 60/1Z1 (00353446-) (f. Segment 1)
SDS 60/0,5D1 (00353447-) (f. Segment 2)
SDS 60/0,5D1 (00353447-) (f. Segment 1)
Dp 2
C+P 6/12
Gantry 1/2
Twin Head
Gantry 4/3
Free
AxisUnit A363 X-Serie / PA 1+2 / C+P 6/12 - Twin Head
2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits Head Reconfiguration Kits
07/2010 Edition
252
2
TBS 250/10X
TBS 250 /20Y
DBM/3P-06
5 V / 15A 15V/1,7A 15V/ 1,7A
DBM/3P-06
TBS 250/10X
TBS 250 /20Y
DBM/3P-06
SDS 120/2.5S1-03 (00353445-)
SDS 60 3Z1-02 (03002141-)
SDS 60/1D1-02 (03002142-)
DBM/3P-06
15 V / 5A 15 V / 5A
Anti crash board
Gantry
1/2
Gantry
4/3
X
Z
X
Z1
Y
dp
X
Star
Free
Dp 1
Z2
SDS 60/1Z1 (00353446-) (f. Segment 2)
SDS 60/1Z1 (00353446-) (f. Segment 1)
SDS 60/0,5D1 (00353447-) (f. Segment 2)
SDS 60/0,5D1 (00353447-) (f. Segment 1)
Dp 2
Twin Haed
Gantry 1/2
C+P 6/12
Gantry 4/3
AxisUnit A363 X-Serie / PA 1+2 / Twin Head - C+P 6/12
Head Reconfiguration Kits 2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits
07/2010 Edition
253
2
TBS 250/10X
DBM/3P-06
SDS 60/1Z1 (00353446-) (f. Segment 2)
DBM/3P-06
SDS 60/0,5D1 (00353447-) (f. Segment 2)
TBS 250/20Y
SDS 60/1Z1 (00353446-) (f. Segment 1)
SDS 60/0,5D1 (00353447-) (f. Segment 1)
5 V / 15A 15V/1,7A 15V/ 1,7A
15 V / 5A 15 V / 5A
Anti crash board
BS 250 / 1000 -03
X
Y
Z 2
dp 1
Z 1
dp 2
Gantry 3
Gantry 2
Twin Haed
Gantry 3
AxisUnit A363 X2 + X3 / PA 2 / Twin Head
