1.2 Safety Devices

1.2.1 Protective Covers

Fig. 1.2.1 SIPLACE 80 S/F/G safety devices

- Key to Fig. 1.2.1

➀

Front cover

➁

Double wing door, right-hand side

➂

Cover

➃

Rear cover

➄

Cover

➅

Double wing door, left-hand side

1 Operational Safety SIPLACE 80 S/F/G Service Manual

Edition 04/97

1 - 8

1.2.1.1 General Comments

The travel area of the gantries is protected by two covers. These covers are locked during the placement pro-

cess. If you wish to open the covers you will have to either unlock the key-operated switch or press the STOP

button. If the top covers, the front or rear covers are opened when the key-operated switch is in the locked

position the gantries will come to an immediate stop. The gantry axes will be de-energized.

Pressing the EMERGENCY STOP button will stop placement. Placement of the board can then be resumed

or aborted.

The lateral double wing doors can be removed when the machine is stationary to allow filling with fresh com-

ponents.

WARNING

When the key-operated switch is unlocked, only correspondingly qualified and trained personnel are permit-

ted to open the protective covers.
