Dual-Simultaneous Programmable Pitch Owner’s Manual Safety
© 2024 Nordson Corporation 5
• If possible, save or recycle unused materials. Refer to the SDS before saving or recycling
unused materials.
• DO NOT dispense toxic fluids (materials with a TLV of 200 ppm or lower).
2.3.3 Preventing Applicator and Workpiece Damage
• Immediately press the Emergency Machine Off (EMO or E-Stop) button on the conformal
coating system if the coating system, DSPP, or a workpiece is in danger of being damaged.
• Use standard Electrostatic Discharge (ESD) precautions when working near sensitive
components. Always wear a grounding strap and connect it to the ESD ground before
handling workpieces and/or equipment.
• Perform all recommended maintenance procedures at the suggested intervals.
• Immediately contain and clean up any caustic or conductive fluid spills as recommended in
the material manufacturer’s SDS.
• If fluid gets into internal portions of the DSPP (that are not normally wetted), immediately
contact Technical Support.
WARNING!
The DSPP is a precision instrument of inherently safe design. The use of any
coating fluid and the related choice of solvent for cleaning, as well as all
associated safety precautions, is the responsibility of the end-user. Refer to the
SDS for recommendations on personal protective equipment and safety practices.
2.4 Decommissioning
Table 2-1 Recommended Decommissioning Procedures
Component Disposition
Aluminum Parts Recycle aluminum parts.
Steel Parts Recycle steel parts and hardware.
Copper Wiring Recycle copper wiring.
Electronic Components Discard in accordance with local safety/environmental regulations.
Pneumatic Components
Recycle or discard in accordance with local safety/environmental
regulations.
Printed Circuit Boards Discard in accordance with local safety/environmental regulations.
Plastics
Recycle or discard in accordance with local safety/environmental
regulations.
2.5 Disposal
Dispose of equipment and materials used in operation and servicing in accordance with local regulations.
Depending on the fluid dispensed and cleaning materials used, the following items may contain
substances whose disposal might be regulated:
• Dispensing Needles
• Fluid Body
• Fittings
Dual-Simultaneous Programmable Pitch Owner’s Manual Safety
6 © 2024 Nordson Corporation
2.6 Emergency Shutdown
In the event of an emergency or malfunction, press the EMO (E-Stop) button on the conformal coating
system and perform the following steps:
• Disconnect and lockout system electrical power. Close hydraulic and pneumatic shutoff
valves and relieve pressure.
• Identify the reason for the malfunction and correct it before restarting the system.
2.7 Safety Warning Labels
Safety warning labels on your equipment point out areas where personnel must use extreme caution to
prevent serious injury and property damage. Refer to the applicable coating system Installation,
Operations, and Maintenance Manual for important safety information and conformal coating system label
locations.
WARNING!
Comply with all safety warning labels on the conformal coating system and
optional equipment or serious injury to personnel or damage to the conformal
coating system may occur. Replace worn or damaged labels.
© 2024 Nordson Corporation 7
3 Installation and Configuration
3.1 Overview
The DSPP should come already installed and configured for your conformal coating system. The DSPP
may need minor adjustments from time to time, or after changing applicators. This section includes the
following instructions:
•
Adjusting Limit Sensor
•
Adjusting Y
-
•
Adjusting Applicator Height
•
Third Valve Option
•
Adjusting Applicator Pitch
3.2 Safety First
Operation of the Dual-Simultaneous Programmable Pitch involves mechanical devices and electrical
power. It is essential that every person servicing or operating the DSPP fully understands all hazards,
risks, and safety precautions. See Section 2 - Safety for additional information.
WARNING!
Allow only qualified personnel to perform the following tasks. Follow the safety
instructions in this document and all other related documentation.
WARNING!
Ensure the fluid system is completely depressurized prior to loosening any fittings
in the fluid path. Failure to do so may cause serious injury to personnel.
3.3 Tools and Materials Needed
• Torque Wrench
• Metric Hex Key Set
3.4 Unpacking the DSPP
Every care has been taken when packaging the DSPP. However, we recommend that you look for
obvious damage and verify contents against the packing slip.
Retain the case for storage of the DSPP and accessories. Retain shipping cartons for future use. If an
item needs to be returned to Nordson, obtain a Return Material Authorization (RMA) number from
Nordson, see 7.3 Parts Ordering Information.
