Dual-Simultaneous Programmable Pitch Owner’s Manual Parts Replacement

7.3.2 Shipping Instructions

When ordering parts, specify which carrier you prefer to use and provide your shipping account number. If

no instructions are received, Nordson will determine the best shipping method and items will be shipped

prepaid with the shipping charge added to the invoice.

7.4 Warranty

Contact Technical Support for any warranty issues pertaining to spare parts. Wear items and

consumables are covered under warranty against manufacturer defect only. Expected lifetimes for these

parts will vary based upon application and use.

Consumable parts are generally considered as parts that are replaced on a frequency of > 1 per calendar

year under expected regular usage. In most cases, these parts are “wetted parts” that make contact with

the dispensed fluid. Wear items are those items that have been identified to have limited life expectancy

(less than 5 years) but are not considered consumables. Wear items are often highly application

dependent, high user-touch, or adjusted parts.

7.5 Credit and Exchanges

Contact Technical Support for credit or exchanges of recommended spare parts or refurbished

components (components restored to original specifications but not sold as new).

7.5.1 Return Material Authorization

Contact Technical Support to obtain a Return Material Authorization (RMA) before returning any parts.

NOTE

Find your local Technical Support contact on the web page, www.nordsonasymtek.com.

7.6 Record Keeping

The type of service performed should be recorded in the PreciseCoat Jet maintenance records. Dates,

part numbers/serial numbers of replaced parts, names of technicians, and other pertinent data should be

recorded.

7.7 Unpacking and Inspecting Replacement Parts

Replacement parts are shipped to distributor or customer facilities in individual shipping cartons. Review

the packing slip to ensure that the correct parts were received. Contact Technical Support if any

discrepancies are discovered.

Before unpacking your spare parts, visually inspect the carton for damage. If applicable, check the

ShockWatch and the Tip N’ Tell stickers for indications of improper shipping and handling. Inform the

freight carrier of any damage.

7.8 Cleaning and Inspection

Always clean the area made visible after a failed part is removed from the dispensing system. Inspect the

area for signs of what may have caused the part to fail. This may help prevent future part damage. When

removing parts that will be reinstalled, visually inspect them for damage. If undamaged, retain them for

reinstallation. Replace damaged parts and hardware as appropriate.

Dual-Simultaneous Programmable Pitch Owner’s Manual Parts Replacement

7.9 Spare Parts List

Use the following tables to locate the item number corresponding to a procedure in this technical manual.

Nearly all spare parts are sold as part of a spares kit, with a few exceptions. To order parts, access

www.nordson.com/electronics, use the search feature to search for a kit part number or part description to

locate the appropriate spares list, and follow the instructions in that file to complete the ordering process.

Contact Technical Support for questions.

7.9.1 Spare Parts List for DSPP

Table 7-1 Spare Parts List

Kit Part

Number

Kit Name

Item

Number

Part Description Quantity

6653665

FRU, DSPP, SPARES KIT, SL-1040

MOTOR, NEMA 17 W/ENCOD 200 LINE

PWA, AUTO-PITCH, SW, 5V, SL94X

BELT, MXL 4.8MM W X 71 TEETH

ACTUATOR, LINEAR 174MM STROKE

CABLE, ENCD 112Q, HOME-LIMIT SW

CABLE, AUTO-PITCH, MOTOR ASSY

ASSY, CONTROLLED, DSPP, 1040

6651398

ASSY, CONTROLLER, DSPP, 1040

CLIP,WIRE HARNESS,.500 ID

WASHER, #8 INTERNAL STAR

CLIP, WIRE HARNESS

SCREW, M3 X 10MM, SOCKET CAP

COVER,PROG PITCH CNTRL

ENCLOSURE, PROG PITCH CNTRL,1040

CABLE,AUTO-PITCH,RS422,V2

SCREW,D M4X6,SS,SOC HEAD

CLAMP,RAIL,DIN

POWER SUPPLY, 96W, 24V, DIN

SOCKET 2 POLE

RELAY,DPDT,24VDC,5A,LED, DIODE

ADAPTER,USB-RS232,ISOLATED

SCREW,M2-0,4X6 SOCKET CAP

SCREW,M5-0.8X6 SOCKET CAP,SS

BRKT,DSPP CONTROLER MOUNT

SCREW, M6X8, SOCK CAP, SS

CABLE,AUTOPITCH,PWR,INTLK,IN

DIN RAIL,SLOT,35x7.5x90mm

CABLE,AUTOPITCH,LINE IN,KIT 1040

SCREW, M4X0.7, PHILIPS PAN, X8

CONTROL, STEPPER DRIVE W/ENCODER

Dual-Simultaneous Programmable Pitch Owner’s Manual Parts Replacement

Kit Part

Number

Kit Name

Item

Number

Part Description Quantity

6651385

ASSY, DSPP AXIS, 1040

SCREW,SHCS,M4X 0.7X14,SS

WASHER, FLAT M3

SCREW, M3 X 0.5 PH FLAT X 10

SCREW M3X0.5 SOCKET X 4

SCREW, M3 X 0.5 SOCKET X 6

SCREW, M3 X 0.5 SOCKET X 8

SOCKET CAP SCREW, M3 X 12

SCREW, M3X.5X16 SOCKET HEAD

WASHER, FLAT M4

NUT, HEX M5 X 0.8

MOTOR,NEMA 17 W/ENCOD 200 LINE

COVER,LIMIT SENSOR

HOME FLAG,MINIBOT

PULLEY,MXL 3.0 mm ID,4.8BLT,20T

ACTUATOR,LINEAR 174MM STROKE

BELT,MXL 4.8mm W X 71 TEETH

BASE PLATE,DSPP AXIS,1040

MNT BRKT,DSPP BASE PLATE,1040

MNT BRKT,DSPP ASSY TO Z-AXIS,1040

MNT BRKT,DSPP FIXED APPLICATOR,1040

SCREW,SHOULDER,M5X0.7 X 12 LG

COVER,BELT,DSPP,1040

NUT, HEX M3 X 0.5

NUT, HEX M4 X 0.7

SCREW, M3X.5 X 8MM LNG.BUTTON

SCREW,M4X18 SOC HEAD CAP SS.

SCREW,SHOULDER 5MM ODX

PULLEY, MXL 5mmID, 4.8BLT, 20T

MOUNT, MOTOR NEMA 17

PWA,AUTO-PITCH,SW,5V,SL94X

SCREW, SET, M3X.05X6, SS

TOOL, DSPP, ALIGNMENT FIXED MOUNT

CLIP,WIRE HARNESS,.250 ID

SCREW, M5X0.8,FLAT TIP SET, X8

SCREW,M4X0.7 BUTTON HEAD,X6

SCREW, M5 X 0.8 SOCKET X 16

SCREW, M4 X 0.7, SOCKET X 10

PLATE,VALVE MOUNT PRG PITCH V2,1040
