User manual SIPLACE X-Series 3 Technical data and assemblies From software version 708.1 Version 05/2015 3.10 Component trolley 207 3.10.2 Description In the sta ndard version, the t ape reel container (item 3 in fig. 3.…
3 Technical data and assemblies User manual SIPLACE X-Series
3.10 Component trolley From software version 708.1 Version 05/2015
206
3.10.1 Structure
The component trolley essentially consists of the chassis, the changeover table for holding the
feeder modules, the tape reel container and the waste tape container.
3
Fig. 3.10 - 3 Component trolley, SIPLACE X-Series, front and rear view
(1) Chassis
(2) Changeover table
(3) Tape container
(4) Gap for accommodation of setup lists
(5) Waste tape container
(6) Handle
(7) Hand guard
3
3
CAUTION
Observe the safety instructions!
Observe the safety instructions in section 5.8.2, page 293 when you pull the tape re-
ject bin out of the component trolley.
CAUTION
Risk of breaking handles!
Risk of breaking handles when transporting the component trolley.
When transporting the component trolley, do not lift it by its handles.
Only use the handles to push the component trolley.
Use a fork-lift if you want to transport the component trolley or lift it off the pallet.
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 708.1 Version 05/2015 3.10 Component trolley
207
3.10.2 Description
In the standard version, the tape reel container (item 3 in fig. 3.10 - 3) holds tape reels up to a size
of 17" (432 mm).
There are two 5 mm wide gaps on the left and right, between the tape container and the compo-
nent trolley (item. 4 in fig. 3.10 - 3
, page 206) for holding setup lists.
The pullout waste tape container can be found beneath the chassis (item 5 in fig. 3.10 - 3
, page
206
). The cut waste tape travel down a chute into the waste tape container, which must be emp-
tied as it fills up.
The handles (item 6 in fig. 3.10 - 3
, page 206) can be folded up or down.
3
PLEASE NOTE
All component trolleys must be docked onto the
machine in order to operate it.
Fill any free locations with dummy feeder modules as described in
section 2.6.6
, page 93.
3 Technical data and assemblies User manual SIPLACE X-Series
3.10 Component trolley From software version 708.1 Version 05/2015
208
3.10.3 Technical data
3
3
Length x width 727 x 592 mm²
752 x 592 mm² with waste container
Height of the changeover table 890 mm for 900 mm PCB conveyor height
920 mm for 930 mm PCB conveyor height
940 mm for 950 mm PCB conveyor height
PCB conveyor height 900 mm ± 15 mm (option)
930 mm ± 15 mm (standard)
950 mm ± 15 mm (SMEMA option)
Height of handles when folded out 969 mm
Number of locations 40 (8 mm X tape feeder module)
Weight
Without feeder modules
With feeder module at all locations
80.4 kg
139.6 kg
Tape reel diameter
Standard
Maximum
Up to 432 mm (17")
483 mm (19")
