CMV12000
Register Description
Datasheet • PUBLIC
DS000603 • v6-00 • 2023-Sep-22
84 │ 71
8 Register Description
8.1 Register Categories
The registers are grouped into various categories, based on when they may (or not may) be updated
and synced. The table below explains the details of the various categories.
Figure 97:
Register Categories
Category
Description
-
Register without category that can be uploaded at any time, but might directly influence the
sensor execution.
SYNC
Registers are internally synchronized to the end of FOT, so the read out will be done with these
registers applied.
Registers can only be uploaded during IDLE or FOT.
FRAME
Registers will be internally synced at FRAME_REQ.
Registers can only be uploaded during IDLE.
INTE
Registers will be internally synced at start of INTE.
Registers can only be uploaded during IDLE or FOT.
DC
Registers will be internally synced immediately.
Registers can only be uploaded during IDLE or FOT.
IDLE
Registers will be internally synced immediately.
Registers can only be uploaded when the sensor is IDLE.
RO
Registers can be read only.
8.2 Register Overview
Below is an overview of all registers, together with their default value after reset/startup. Some
registers have to be changed to another fixed value after reset/startup, independent on the sensor
control or modes. This value is in the last column.
Figure 98:
Register Overview
Address
Register Name(s)
Category
Default Value
Fixed Value
0
-
0
1
Number_lines_tot[15:0]
SYNC
3072
2
Y_start_1[15:0]
SYNC
0
3
Y_start_2[15:0]
SYNC
0
4
Y_start_3[15:0]
SYNC
0
CMV12000
Register Description
Datasheet • PUBLIC
DS000603 • v6-00 • 2023-Sep-22
84 │ 72
Address
Register Name(s)
Category
Default Value
Fixed Value
5
Y_start_4[15:0]
SYNC
0
6
Y_start_5[15:0]
SYNC
0
7
Y_start_6[15:0]
SYNC
0
8
Y_start_7[15:0]
SYNC
0
9
Y_start_8[15:0]
SYNC
0
10
Y_start_9[15:0]
SYNC
0
11
Y_start_10[15:0]
SYNC
0
12
Y_start_11[15:0]
SYNC
0
13
Y_start_12[15:0]
SYNC
0
14
Y_start_13[15:0]
SYNC
0
15
Y_start_14[15:0]
SYNC
0
16
Y_start_15[15:0]
SYNC
0
17
Y_start_16[15:0]
SYNC
0
18
Y_start_17[15:0]
SYNC
0
19
Y_start_18[15:0]
SYNC
0
20
Y_start_19[15:0]
SYNC
0
21
Y_start_20[15:0]
SYNC
0
22
Y_start_21[15:0]
SYNC
0
23
Y_start_22[15:0]
SYNC
0
24
Y_start_23[15:0]
SYNC
0
25
Y_start_24[15:0]
SYNC
0
26
Y_start_25[15:0]
SYNC
0
27
Y_start_26[15:0]
SYNC
0
28
Y_start_27[15:0]
SYNC
0
29
Y_start_28[15:0]
SYNC
0
30
Y_start_29[15:0]
SYNC
0
31
Y_start_30[15:0]
SYNC
0
32
Y_start_31[15:0]
SYNC
0
33
Y_start_32[15:0]
SYNC
0
34
Y_size_1[15:0]
SYNC
0
35
Y_size_2[15:0]
SYNC
0
36
Y_size_3[15:0]
SYNC
0
37
Y_size_4[15:0]
SYNC
0
38
Y_size_5[15:0]
SYNC
0
39
Y_size_6[15:0]
SYNC
0
40
Y_size_7[15:0]
SYNC
0
41
Y_size_8[15:0]
SYNC
0
42
Y_size_9[15:0]
SYNC
0
43
Y_size_10[15:0]
SYNC
0
44
Y_size_11[15:0]
SYNC
0
CMV12000
Register Description
Datasheet • PUBLIC
DS000603 • v6-00 • 2023-Sep-22
84 │ 73
Address
Register Name(s)
Category
Default Value
Fixed Value
45
Y_size_12[15:0]
SYNC
0
46
Y_size_13[15:0]
SYNC
0
47
Y_size_14[15:0]
SYNC
0
48
Y_size_15[15:0]
SYNC
0
49
Y_size_16[15:0]
SYNC
0
50
Y_size_17[15:0]
SYNC
0
51
Y_size_18[15:0]
SYNC
0
52
Y_size_19[15:0]
SYNC
0
53
Y_size_20[15:0]
SYNC
0
54
Y_size_21[15:0]
SYNC
0
55
Y_size_22[15:0]
SYNC
0
56
Y_size_23[15:0]
SYNC
0
57
Y_size_24[15:0]
SYNC
0
58
Y_size_25[15:0]
SYNC
0
59
Y_size_26[15:0]
SYNC
0
60
Y_size_27[15:0]
SYNC
0
61
Y_size_28[15:0]
SYNC
0
62
Y_size_29[15:0]
SYNC
0
63
Y_size_30[15:0]
SYNC
0
64
Y_size_31[15:0]
SYNC
0
65
Y_size_32[15:0]
SYNC
0
66
Sub_offset[15:0]
SYNC
0
67
Sub_step[15:0]
SYNC
1
68
Color[3], Bin_en[2], Sub_en[1], Color[0]
IDLE
9
69
Image_flipping[1:0]
DC
0
70
Exp_dual[1], Exp_ext[0]
IDLE
0
71
Exp_time[15:0]
INTE
1536
72
Exp_time[23:16]
INTE
0
73
Exp_time2[15:0]
INTE
1536
74
Exp_time2[23:16]
INTE
0
75
Exp_kp1[15:0]
INTE
0
76
Exp_kp1[23:16]
INTE
0
77
Exp_kp2[15:0]
INTE
0
78
Exp_kp2[23:16]
INTE
0
79
Number_slopes[1:0]
INTE
1
80
Number_frames[15:0]
FRAME
1
81
Disable_top[5], Output_mode[4:0]
IDLE
0
82
IDLE
5682
83
IDLE
5893
84
IDLE
130
