Document Feedback CMV12000 Register Description Datasheet • PUBLIC DS000603 • v6 - 00 • 2023 -Sep- 22 84 │ 75 Address Register Name(s) Category Default Value Fixed Value 125 IDLE 2 126 RO 770 127 Temp_sensor[15:0] RO 0
Document Feedback
CMV12000
Register Description
Datasheet • PUBLIC
DS000603 • v6-00 • 2023-Sep-22
84 │ 74
Address
Register Name(s)
Category
Default Value
Fixed Value
85
IDLE
130
86
IDLE
130
87
Offset_bot[11:0]
DC
780
88
Offset_top[11:0]
DC
780
89
Black_col_en[15], Training_pattern[14:0]
-
85
90
Channel_en_bot[15:0]
IDLE
65535
91
Channel_en_bot[31:16]
IDLE
65535
92
Channel_en_top[15:0]
IDLE
65535
93
Channel_en_top[31:16]
IDLE
65535
94
Channel_en[2:0]
IDLE
7
95
ADC_clk_en_bot[15:0]
IDLE
65535
96
ADC_clk_en_top[15:0]
IDLE
65535
97
IDLE
0
98
IDLE
34952
99
IDLE
34952
34956
100
IDLE
0
101
IDLE
0
102
IDLE
8256
8302
103
IDLE
4032
104
IDLE
64
105
IDLE
8256
106
Vtfl3[13:7], Vtfl2[6:0]
IDLE
8256
107
IDLE
12384
108
IDLE
12384
12381
109
Vramp2[13:7], Vramp1[6:0]
IDLE
12384
110
IDLE
12384
12368
111
IDLE
34952
112
IDLE
0
277
113
IDLE
778
114
IDLE
95
115
PGA_div[3], PGA_gain[2:0]
IDLE
0
116
ADC_range_mult[9:8], ADC_range[7:0]
IDLE
383
117
DIG_gain[4:0]
IDLE
4
118
Bit_mode[1:0]
IDLE
1
119
IDLE
0
120
IDLE
9
121
IDLE
1
122
Test_pattern[1:0]
IDLE
32
123
-
0
124
IDLE
5
15
Document Feedback
CMV12000
Application Information
Datasheet • PUBLIC
DS000603 • v6-00 • 2023-Sep-22
84 │ 76
9 Application Information
9.1 Color Filter
For a color version of the CMV12000, the color filters are applied in a Bayer pattern. When flipping in
Y is not enabled (register 69 =0), the first pixel read-out, pixel (0, 0), is the top left one and has a red
filter. If register 69 is ‘2’ (recommended), the bottom left pixel (0, 3071) is read-out first and it has a
green filter.
Figure 99:
Color Filter Layout
Pixel (0,0)
R G R G
G B G B
R G R G
G B G B
R G R G
G B G B
R G R G
G B G B
Pixel (0,3071)
