Document Feedback

CMV12000

Pin Assignment

Datasheet • PUBLIC

DS000603 • v6-00 • 2023-Sep-22

84 │ 7

Number

Name

Type

Description

A10

VDD18

Supply

1.98 V supply

A11

OUT9_N

LVDS output

LVDS negative output channel 9

A12

OUT9_P

LVDS output

LVDS positive output channel 9

A13

OUT13_N

LVDS output

LVDS negative output channel 13

A14

OUT13_P

LVDS output

LVDS positive output channel 13

A15

VDD18

Supply

1.98 V supply

A16

VDD18

Supply

1.98 V supply

A17

OUT19_N

LVDS output

LVDS negative output channel 19

A18

OUT19_P

LVDS output

LVDS positive output channel 19

A19

OUT23_N

LVDS output

LVDS negative output channel 23

A20

OUT23_P

LVDS output

LVDS positive output channel 23

A21

GND

Ground

Ground pin

A22

VDD18

Supply

1.98 V supply

A23

OUT29_N

LVDS output

LVDS negative output channel 29

A24

OUT29_P

LVDS output

LVDS positive output channel 29

A25

GND

Ground

Ground pin

A26

VDD18

Supply

1.98 V supply

A27

VDD18

Supply

1.98 V supply

A28

GND

Ground

Ground pin

A29

GND

Ground

Ground pin

A30

VDD_PIX

Supply

3.0 V supply

CMD_COL_LOAD

Bias

Decouple with 100 nF to VDD33

VTREF

Analog input

Test pin (decouple with 100 nF to GND)

VREF_ADC

Bias

Reference for ADC (decouple with 100 nF to GND)

VDD18

Supply

1.98 V supply

GND

Ground

Ground pin

OUT1_N

LVDS output

LVDS negative output channel 1

OUT1_P

LVDS output

LVDS positive output channel 1

OUT5_N

LVDS output

LVDS negative output channel 5

OUT5_P

LVDS output

LVDS positive output channel 5

B10

OUT8_N

LVDS output

LVDS negative output channel 8

B11

OUT8_P

LVDS output

LVDS positive output channel 8

B12

OUT12_N

LVDS output

LVDS negative output channel 12

B13

OUT12_P

LVDS output

LVDS positive output channel 12

B14

OUT16_N

LVDS output

LVDS negative output channel 16

B15

OUT16_P

LVDS output

LVDS positive output channel 16

B16

OUT18_N

LVDS output

LVDS negative output channel 18

B17

OUT18_P

LVDS output

LVDS positive output channel 18

B18

OUT22_N

LVDS output

LVDS negative output channel 22

B19

OUT22_P

LVDS output

LVDS positive output channel 22

Document Feedback

CMV12000

Pin Assignment

Datasheet • PUBLIC

DS000603 • v6-00 • 2023-Sep-22

84 │ 8

Number

Name

Type

Description

B20

OUT26_N

LVDS output

LVDS negative output channel 26

B21

OUT26_P

LVDS output

LVDS positive output channel 26

B22

GND

Ground

Ground pin

B24

OUT31_N

LVDS output

LVDS negative output channel 31

B25

OUT31_P

LVDS output

LVDS positive output channel 31

B26

GND

Ground

Ground pin

B27

GND

Ground

Ground pin

B28

GND

Ground

Ground pin

B29

CMD_RAMP

Bias

Decouple with 100 nF to VDD33

B30

VTF_LOW2

Bias

Transfer low voltage 2 (decouple with 100 nF to GND)

CMD_LVDS

Bias

Decouple with 100 nF to GND

VTSIG

Analog input

Test pin (decouple with 100 nF to GND)

VCM_COMP33

Bias

Decouple with 100 nF to GND

VPCH_H

Bias

Pre-charge high voltage (decouple with 100 nF to GND)

VTF_LOW0

Bias

Transfer low voltage 0 (connect to GND)

CMD_COLAMP

Bias

Decouple with 100 nF to VDD33

OUT4_N

LVDS output

LVDS negative output channel 4

OUT4_P

LVDS output

LVDS positive output channel 4

OUT7_N

LVDS output

LVDS negative output channel 7

C10

OUT7_P

LVDS output

LVDS positive output channel 7

C11

OUT11_N

LVDS output

LVDS negative output channel 11

C12

OUT11_P

LVDS output

LVDS positive output channel 11

C13

OUT14_N

LVDS output

LVDS negative output channel 14

C14

OUT14_P

LVDS output

LVDS positive output channel 14

C15

GND

Ground

Ground pin

C16

GND

Ground

Ground pin

C17

OUT21_N

LVDS output

LVDS negative output channel 21

C18

OUT21_P

LVDS output

LVDS positive output channel 21

C19

OUT25_N

LVDS output

LVDS negative output channel 25

C20

OUT25_P

LVDS output

LVDS positive output channel 25

C21

OUT28_N

LVDS output

LVDS negative output channel 28

C22

OUT28_P

LVDS output

LVDS positive output channel 28

C24

OUT32_N

LVDS output

LVDS negative output channel 32

C25

OUT32_P

LVDS output

LVDS positive output channel 32

C26

VDD33

Supply

3.3 V supply

C27

VDD33

Supply

3.3 V supply

C28

GND

Ground

Ground pin

C29

VBGAP

Bias

Decouple with 100 nF to GND

C30

VTF_LOW3

Bias

Transfer low voltage 3 (decouple with 100 nF to GND)

CMD_COL_PC

Bias

Decouple with 100 nF to VDD33

Document Feedback

CMV12000

Pin Assignment

Datasheet • PUBLIC

DS000603 • v6-00 • 2023-Sep-22

84 │ 9

Number

Name

Type

Description

GND

Ground

Ground pin

VDD33

Supply

3.3 V supply

VCLAMP

Bias

Decouple with 100 nF to GND

VRES_L

Bias

Reset low voltage (decouple with 100 nF to GND)

VTF_LOW1

Bias

Transfer low voltage 1 (connect to GND)

OUT3_N

LVDS output

LVDS negative output channel 3

OUT3_P

LVDS output

LVDS positive output channel 3

OUT6_N

LVDS output

LVDS negative output channel 6

D10

OUT6_P

LVDS output

LVDS positive output channel 6

D11

OUT10_N

LVDS output

LVDS negative output channel 10

D12

OUT10_P

LVDS output

LVDS positive output channel 10

D13

OUT15_N

LVDS output

LVDS negative output channel 15

D14

OUT15_P

LVDS output

LVDS positive output channel 15

D15

OUT17_N

LVDS output

LVDS negative output channel 17

D16

OUT17_P

LVDS output

LVDS positive output channel 17

D17

OUT20_N

LVDS output

LVDS negative output channel 20

D18

OUT20_P

LVDS output

LVDS positive output channel 20

D19

OUT24_N

LVDS output

LVDS negative output channel 24

D20

OUT24_P

LVDS output

LVDS positive output channel 24

D21

OUT27_N

LVDS output

LVDS negative output channel 27

D22

OUT27_P

LVDS output

LVDS positive output channel 27

D23

OUT30_N

LVDS output

LVDS negative output channel 30

D24

OUT30_P

LVDS output

LVDS positive output channel 30

D25

GND

Ground

Ground pin

D26

VDD33

Supply

3.3 V supply

D27

GND

Ground

Ground pin

D28

VDD_PIX

Supply

3.0 V supply

D29

GND

Ground

Ground pin

D30

VDD_PIX

Supply

3.0 V supply

VDD18_PLL

Supply

PLL 1.98 V supply (unused)

VDD_RES

Supply

3.3 V supply

GND

Ground

Ground pin

DIO2

Ground

Connect to ground

LVDS_CLK_N

LVDS input

LVDS input clock N

LVDS_CLK_P

LVDS input

LVDS input clock P

OUT35_N

LVDS output

LVDS negative output channel 35

OUT35_P

LVDS output

LVDS positive output channel 35

OUT38_N

LVDS output

LVDS negative output channel 38

E10

OUT38_P

LVDS output

LVDS positive output channel 38

E11

OUT42_N

LVDS output

LVDS negative output channel 42
