x Safety instructions n Label positions W arning/caution labels Other Controller Exchange carriage for ZS feeder ■ T op of controller ■ T op of carriage 93014-KMK-00 Electrical shock hazard Could cause machine damage (co…
ix
Safety instructions
Machine damage Death, serious injury or equipment malfunction
Make sure push-up pins are arranged within specified area
.
Observe precautions necessary due to strong magnetic fields.
Adverse effects on component mounting accuracy
Unexpected accidents may occur if safety mechanisms
are disabled.
Do not touch camera unit or apply impacts to it.
Do not remove or disassemble any specified safety mechanism
(protective cover, safety cover, etc.).
x
Safety instructions
n
Label positions
Warning/caution labels
Other
Controller
Exchange carriage
for ZS feeder
■ Top of controller
■ Top of carriage
93014-KMK-00
Electrical shock hazard Could cause machine damage (collisions with head, etc.).
Before opening covers wait at least 100 seconds after turning
power off.
Verify that no objects have been placed on the top cover of the
feeder exchange carriage.
Could cause machine damage (collisions with head, etc.). Electrical shock hazard
Verify that no objects have been placed on the top cover of
the feeder exchange carriage.
Do not touch while power is supplied.
xi
Safety instructions
n
Label positions of sATS30 and cATS10
Warning/caution labels
sATS30 and cATS10
■ Door opening
sATS30
■ Base cover
■ Base cover
cATS10
■ Door opening
93015-KMK-00
Injury from touching moving parts during machine operation Electrical shock hazard
Do not touch or tamper with safety cover switches and do not
operate machine if any safety cover switches were deactivated.
Do not touch power supply inside cover.
· Hands or fingers might be caught between moving parts
and covers, causing injury.
· Hands or fingers might be pinched by moving parts,
causing injury.
Never place hands or fingers in machine during operation
such as when handling tray magazines.
