A-6
Appendix
2.2 YSM20R main unit maintenance parts list
c
CAUTION
The parts (Part Nos.) in this manual are at the time of issuing this manual. The Part Nos. may be changed without prior
notice. Make sure to verify the latest Part Nos. before ordering.
n
Maintenance parts list for
YSM20R Dual-stage type
Position Name Part name Part No. Note Qty
HM
head
unit
Single item for
head valve
Valve for ejector
vacuum generation
VALVE KLF-M7152-00X
Valve for ejector
vacuum generation
10
*1
Valve for ejector burst
pressure generation
VALVE KLF-M7153-00X 10
*1
Blow valve for cleaning VALVE KLW-M7158-00X 1
*1
Spare ejector EJECTOR KLW-M7157-10X
Valve per head and
ejector unit
10
*1
Valve peripheral
parts
Ejector bit BIT KLW-M7154-00X 10
*1
Bit cap BIT CAP KLW-M7156-00X Cap for ejector bit 10
*1
Muffler MUFFLER KLW-M715A-00X Muffler in bit cap 10
*1
Filter cap FILTER CAP KLW-M7155-00X 10
*1
Vacuum sensor Vacuum sensor board
VAC SENSOR BRD
ASSY
KHY-M4592-01X 1
*1
R-axis operation
R-axis shaft for tension
pulley
SHAFT2,TENSION KKE-M7126-00X 2
*1
R-axis drive belt BELT1 KHY-M7131-00X 2
*1
R-axis drive belt BELT2 KHY-M7132-00X 2
*1
R-axis shaft for tension
pulley
SHAFT1,TENSION KV8-M7115-00X 4
*1
R-axis shaft for tension
pulley
SHAFT3,TENSION KKE-M7128-00X 2
*1
Bearing BEARING 90933-03J128 16
*1
Circlip CIRCLIP 99009-07800 2
*1
Washer for tension
pulley
WASHER PLAIN 92902-04200 6
*1
Z-axis operation Z-axis linear motor Z UNIT ASSY. KLW-M71G5-00X 10
*1
FM
head
unit
Single item for
head valve
Valve for ejector
vacuum generation
VALVE KLF-M7152-00X
Valve for ejector
vacuum generation
5
*1
Valve for ejector burst
pressure generation
VALVE KLF-M7153-00X 5
*1
Blow valve for cleaning VALVE KLW-M7158-00X 1
*1
Spare ejector EJECTOR KLW-M7157-10X
Valve per head and
ejector unit
5
*1
Valve peripheral
parts
Ejector bit BIT KLW-M7154-00X 5
*1
Bit cap BIT CAP KLW-M7156-00X Cap for ejector bit 5
*1
Muffler MUFFLER KLW-M715A-00X Muffler in bit cap 5
*1
Filter cap FILTER CAP KLW-M7155-00X 5
*1
Vacuum sensor Vacuum sensor board VAC5 SENS BRD ASSY KHY-M4592-10X 1
*1
R-axis operation R-axis drive belt BELT KLW-M74RA-00X 5
*1
Z-axis operation Z-axis ball screw BALL SCREW KLW-M7421-00X 5
*1
Z-axis guide GUIDE,Z KLW-M7425-00X 5
*1
A-7
Appendix
Position Name Part name Part No. Note Qty
Nozzle
Station
Nozzle station
(Common in HM/
FM )
Cylinder for ANC
shutter
CYL.ANC OP/CL ASSY KLW-M653S-00X 1
*2
ANC sensor board
ANC CTRL BOARD
ASSY
KLW-M45BA-00X 1
*2
ANC shutter drive valve VALVE KLW-M91V1-00X 1
*2
Blow station Air filter FILTER,SPARE KGR-M9934-F0X 1
*3
Feeder
exchange
carriage
Carriage feeder
plate
Guide rail
(machine side) 1
RAIL GUIDE 12P KHY-M371R-00X 2
*4
Guide rail
(machine side) 2
RAIL GUIDE 12P KKG-M371R-00X 1
*4
Guide rail (machine
side) mounting screw
SCREW, FLAT HEAD 98702-03006 28
*4
Guide rail (center) 1 GUIDE,FEEDER UNDER KHY-M372R-00X 2
*4
Guide rail (center) 2 GUIDE,FEEDER UNDER KKG-M372R-00X 1
*4
Guide rail (front) 1 GUIDE,FEEDER UNDER KLF-M375X-50X 2
*4
Guide rail (front) 2 GUIDE,FEEDER UNDER KLF-M375X-00X 1
*4
Guide rail (center/front)
mounting screw
SCREW, BINDING HEAD 98902-03004 70
*4
Tape
cutter
Tape cutter
(70-position)
Tape cutter lower blade
set
CUTTER,LOWER 70 KLW-M3T57-A0X 1
*5
Tape cutter upper blade
(left)
CUTTER,UPPER L 70 KLW-M3T55-00X 1
*5
Tape cutter upper blade
(right)
CUTTER,UPPER R 70 KLW-M3T56-00X 1
*5
Shock absorber for
tape cutter
SHOCK ABSORBERS KLW-M3T0D-00X 2
*5
Block for mounting
shock absorber
BLOCK,ABSORBER KLW-M3T0C-00X 2
*5
Tape cutter
(32-position)
Tape cutter upper blade
(32-position)
CUTTER UPPER,384 KJJ-M3T05-10X 1
*5
Tape cutter lower blade
set (32-position)
CUTTER LOWER,384 KJJ-M3T07-B0X 1
*5
Shock absorber for
tape cutter
SHOCK ABSORBERS KLW-M3T0D-00X 1
*5
Block for mounting
shock absorber
BLOCK,ABSORBER KLW-M3T0C-00X 1
*5
X-axis
X-axis
ball screw
X-axis ball screw BALL SCREW KLW-M2271-00X 1
*6
Ball screw support unit SUPPORT UNIT KHN-M2221-00X 1
*6
Spacer SPACER KHN-M224D-00X 1
*6
Spacer SPACER KHN-M2248-00X 2
*6
Lock nut LOCK NUT KGS-M2628-00X 1
*6
Lock nut LOCK NUT KG2-M9173-00X 1
*6
Bearing BEARING 90990-26J022 1
*6
Bolt
BOLT HEX.SOCKET
HEAD
91312-05018 4
*6
X-axis guide X-axis linear guide GUIDE SET,X AXIS KLW-M2276-00X 1
*6
Guide mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04014 34
*6
X-axis duct
common in A/B
Cable duct DUCT,CABLE KMK-M2267-00X 1
*6
Center tape for
protecting cable
TAPE,X DUCT 1 KMK-M220A-00X 1
*6
Outer periphery tape
for protecting cable
TAPE,X DUCT 2 KMK-M220B-00X 1
*6
Inner periphery tape for
protecting cable
TAPE,X DUCT 3 KMK-M220C-00X 1
*6
A-8
Appendix
Position Name Part name Part No. Note Qty
X-axis
X-axis duct
common in A/B
Mounting bolt
BOLT,HEX.SOCKET
HEAD
90990-01J058 4
*6
Mounting bolt BOLT, THIN HEAD 90990-46J011 12
*6
Mounting screw
BOLT,HEX.SOCKET
HEAD
91312-04010 8
*6
Harness in duct
power/emergency stop
HNS,X-FLEX H.PWR
EMG
KLW-M664F-00X
Harness No.
J0076/J0079
1
*6
Harness in duct
ground wire
HNS EARTH 90K30-544110
Harness No.
J0670/J0672
1
*6
Harness in duct
SC-axis motor
HNS,X-FLEX SCM KLW-M66E8-00X
Harness No.
J0169/J0174
1
*6
Harness in duct
camera wiring
HNS,X-FLEX CAMERA KLW-M66K1-00X
Harness No.
J0701/J0703
1
*6
LAN cable in duct HNS,X-ELEX LAN KLW-M66B3-00X
Harness No.
J0183/J0188
1
*6
Harness in duct
SC-axis motor encoder
HNS,X-FLEX SCP KMK-M66AB-00X
Harness No.
J0127/J0132
1
*6
Y-axis
Y-axis guide
Linear guide set for
TypeSV
GUIDE SET,Y AXIS KLW-M2676-00X 2 for YA/YB 1
Guide mounting bolt for
TypeSV
BOLT HEX.SOCKET
HEAD
90990-01J003 56
Y-axis LM guide set for
TypePV (Type A)
GUIDE SET,Y AXIS KMK-M2676-00X 2 for YA/YB
1
*9
Guide mounting bolt for
TypePV (Type A)
BOLT HEX.SOCKET
HEAD
91312-06025
56
*9
Y-axis LM guide set for
TypePV (Type B)
GUIDE SET,Y AXIS KMK-M2676-20X 2 for YA/YB
1
*9
Guide mounting bolt for
TypePV (Type B)
BOLT HEX.SOCKET
HEAD
91312-06025
56
*9
Y-axis duct
(YA: right side)
Center tape for
protecting cable
TAPE,Y DUCT 1 KMK-M260B-00X 1
Outer periphery tape
for protecting cable
TAPE,Y DUCT 2 KMK-M260C-00X 1
Inner periphery tape for
protecting cable
TAPE,Y DUCT 3 KMK-M260D-00X 1
Cable mounting plate PLATE, NUT KV7-M2266-00X 2
Cable support bracket BRACKET,HARNESS KHY-M2669-00X 2
Cable duct DUCT,CABLE KMK-M2678-00X 1
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J032 8
Mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04010 4
Mounting screw SCREW, PAN HEAD 98502-03004 4
Harness in duct
power/emergency stop
HNS,Y-FLEX H.PWR
EMG
KLW-M664E-00X Harness No. J0075 1
Harness in duct
Y-axis motor encoder 1
HNS,Y-FLEX Y1P KMK-M66A7-00X Harness No. J0123 1
Harness in duct
Y-axis motor encoder 2
HNS,Y-FLEX Y2P KMK-M66A8-00X Harness No. J0124 1
Harness in duct
X-axis motor encoder
HNS,Y-FLEX XP KMK-M66AF-00X Harness No. J0125 1
Harness in duct
SC-axis motor encoder
HNS,Y-FLEX SCP KMK-M66AA-00X Harness No. J0126 1
Harness in duct
Y-axis motor 1
HNS,Y-FLEX Y1M KLW-M66E4-00X Harness No. J0165 1
Harness in duct
Y-axis motor 2
HNS,Y-FLEX Y2M KLW-M66E5-00X Harness No. J0166 1
