A-8 Appendix Position Name Part name Part No. Note Qty X-axis X-axis duct common in A/B Mounting bolt BOL T ,HEX.SOCKET HEAD 90990-01J058 4 *6 Mounting bolt BOL T , THIN HEAD 90990-46J01 1 12 *6 Mounting screw BOL T ,HEX…
A-7
Appendix
Position Name Part name Part No. Note Qty
Nozzle
Station
Nozzle station
(Common in HM/
FM )
Cylinder for ANC
shutter
CYL.ANC OP/CL ASSY KLW-M653S-00X 1
*2
ANC sensor board
ANC CTRL BOARD
ASSY
KLW-M45BA-00X 1
*2
ANC shutter drive valve VALVE KLW-M91V1-00X 1
*2
Blow station Air filter FILTER,SPARE KGR-M9934-F0X 1
*3
Feeder
exchange
carriage
Carriage feeder
plate
Guide rail
(machine side) 1
RAIL GUIDE 12P KHY-M371R-00X 2
*4
Guide rail
(machine side) 2
RAIL GUIDE 12P KKG-M371R-00X 1
*4
Guide rail (machine
side) mounting screw
SCREW, FLAT HEAD 98702-03006 28
*4
Guide rail (center) 1 GUIDE,FEEDER UNDER KHY-M372R-00X 2
*4
Guide rail (center) 2 GUIDE,FEEDER UNDER KKG-M372R-00X 1
*4
Guide rail (front) 1 GUIDE,FEEDER UNDER KLF-M375X-50X 2
*4
Guide rail (front) 2 GUIDE,FEEDER UNDER KLF-M375X-00X 1
*4
Guide rail (center/front)
mounting screw
SCREW, BINDING HEAD 98902-03004 70
*4
Tape
cutter
Tape cutter
(70-position)
Tape cutter lower blade
set
CUTTER,LOWER 70 KLW-M3T57-A0X 1
*5
Tape cutter upper blade
(left)
CUTTER,UPPER L 70 KLW-M3T55-00X 1
*5
Tape cutter upper blade
(right)
CUTTER,UPPER R 70 KLW-M3T56-00X 1
*5
Shock absorber for
tape cutter
SHOCK ABSORBERS KLW-M3T0D-00X 2
*5
Block for mounting
shock absorber
BLOCK,ABSORBER KLW-M3T0C-00X 2
*5
Tape cutter
(32-position)
Tape cutter upper blade
(32-position)
CUTTER UPPER,384 KJJ-M3T05-10X 1
*5
Tape cutter lower blade
set (32-position)
CUTTER LOWER,384 KJJ-M3T07-B0X 1
*5
Shock absorber for
tape cutter
SHOCK ABSORBERS KLW-M3T0D-00X 1
*5
Block for mounting
shock absorber
BLOCK,ABSORBER KLW-M3T0C-00X 1
*5
X-axis
X-axis
ball screw
X-axis ball screw BALL SCREW KLW-M2271-00X 1
*6
Ball screw support unit SUPPORT UNIT KHN-M2221-00X 1
*6
Spacer SPACER KHN-M224D-00X 1
*6
Spacer SPACER KHN-M2248-00X 2
*6
Lock nut LOCK NUT KGS-M2628-00X 1
*6
Lock nut LOCK NUT KG2-M9173-00X 1
*6
Bearing BEARING 90990-26J022 1
*6
Bolt
BOLT HEX.SOCKET
HEAD
91312-05018 4
*6
X-axis guide X-axis linear guide GUIDE SET,X AXIS KLW-M2276-00X 1
*6
Guide mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04014 34
*6
X-axis duct
common in A/B
Cable duct DUCT,CABLE KMK-M2267-00X 1
*6
Center tape for
protecting cable
TAPE,X DUCT 1 KMK-M220A-00X 1
*6
Outer periphery tape
for protecting cable
TAPE,X DUCT 2 KMK-M220B-00X 1
*6
Inner periphery tape for
protecting cable
TAPE,X DUCT 3 KMK-M220C-00X 1
*6
A-8
Appendix
Position Name Part name Part No. Note Qty
X-axis
X-axis duct
common in A/B
Mounting bolt
BOLT,HEX.SOCKET
HEAD
90990-01J058 4
*6
Mounting bolt BOLT, THIN HEAD 90990-46J011 12
*6
Mounting screw
BOLT,HEX.SOCKET
HEAD
91312-04010 8
*6
Harness in duct
power/emergency stop
HNS,X-FLEX H.PWR
EMG
KLW-M664F-00X
Harness No.
J0076/J0079
1
*6
Harness in duct
ground wire
HNS EARTH 90K30-544110
Harness No.
J0670/J0672
1
*6
Harness in duct
SC-axis motor
HNS,X-FLEX SCM KLW-M66E8-00X
Harness No.
J0169/J0174
1
*6
Harness in duct
camera wiring
HNS,X-FLEX CAMERA KLW-M66K1-00X
Harness No.
J0701/J0703
1
*6
LAN cable in duct HNS,X-ELEX LAN KLW-M66B3-00X
Harness No.
J0183/J0188
1
*6
Harness in duct
SC-axis motor encoder
HNS,X-FLEX SCP KMK-M66AB-00X
Harness No.
J0127/J0132
1
*6
Y-axis
Y-axis guide
Linear guide set for
TypeSV
GUIDE SET,Y AXIS KLW-M2676-00X 2 for YA/YB 1
Guide mounting bolt for
TypeSV
BOLT HEX.SOCKET
HEAD
90990-01J003 56
Y-axis LM guide set for
TypePV (Type A)
GUIDE SET,Y AXIS KMK-M2676-00X 2 for YA/YB
1
*9
Guide mounting bolt for
TypePV (Type A)
BOLT HEX.SOCKET
HEAD
91312-06025
56
*9
Y-axis LM guide set for
TypePV (Type B)
GUIDE SET,Y AXIS KMK-M2676-20X 2 for YA/YB
1
*9
Guide mounting bolt for
TypePV (Type B)
BOLT HEX.SOCKET
HEAD
91312-06025
56
*9
Y-axis duct
(YA: right side)
Center tape for
protecting cable
TAPE,Y DUCT 1 KMK-M260B-00X 1
Outer periphery tape
for protecting cable
TAPE,Y DUCT 2 KMK-M260C-00X 1
Inner periphery tape for
protecting cable
TAPE,Y DUCT 3 KMK-M260D-00X 1
Cable mounting plate PLATE, NUT KV7-M2266-00X 2
Cable support bracket BRACKET,HARNESS KHY-M2669-00X 2
Cable duct DUCT,CABLE KMK-M2678-00X 1
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J032 8
Mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04010 4
Mounting screw SCREW, PAN HEAD 98502-03004 4
Harness in duct
power/emergency stop
HNS,Y-FLEX H.PWR
EMG
KLW-M664E-00X Harness No. J0075 1
Harness in duct
Y-axis motor encoder 1
HNS,Y-FLEX Y1P KMK-M66A7-00X Harness No. J0123 1
Harness in duct
Y-axis motor encoder 2
HNS,Y-FLEX Y2P KMK-M66A8-00X Harness No. J0124 1
Harness in duct
X-axis motor encoder
HNS,Y-FLEX XP KMK-M66AF-00X Harness No. J0125 1
Harness in duct
SC-axis motor encoder
HNS,Y-FLEX SCP KMK-M66AA-00X Harness No. J0126 1
Harness in duct
Y-axis motor 1
HNS,Y-FLEX Y1M KLW-M66E4-00X Harness No. J0165 1
Harness in duct
Y-axis motor 2
HNS,Y-FLEX Y2M KLW-M66E5-00X Harness No. J0166 1
A-9
Appendix
Position Name Part name Part No. Note Qty
Y-axis
Y-axis duct
(YA: right side)
Harness in duct
X-axis motor
HNS,Y-FLEX XM KMK-M66EE-00X Harness No. J0167 1
Harness in duct
SC-axis motor
HNS,Y-FLEX SCM KLW-M66E7-00X Harness No. J0168 1
LAN cable in duct HNS,Y-FLEX LAN KLW-M66B2-00X Harness No. J0182 1
Harness in duct
Y-axis DI (limit)
HNS,Y-FLEX Y SAFE KMK-M66F8-00X Harness No. J0259 1
Harness in duct
X-axis DI
HNS,Y-FLEX X DI KMK-M66H4-00X Harness No. J0356 1
Harness in duct
ground wire
HNS,EARTH 90K30-544160 Harness No. J0669 1
Harness in duct
camera wiring
HNS,YA-FLEX CAMERA KLW-M66K0-00X Harness No. J0701 1
Y-axis
Y-axis duct
(YB: left side)
Center tape for
protecting cable
TAPE,Y DUCT 1 KMK-M260B-00X 1
Outer periphery tape
for protecting cable
TAPE,Y DUCT 2 KMK-M260C-00X 1
Inner periphery tape for
protecting cable
TAPE,Y DUCT 3 KMK-M260D-00X 1
Cable mounting plate PLATE, NUT KV7-M2266-00X 2
Cable support bracket BRACKET,HARNESS KHY-M2669-00X 2
Cable duct DUCT,CABLE KMK-M2678-00X 1
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J032 8
Mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04010 4
Mounting screw SCREW, PAN HEAD 98502-03004 4
Harness in duct
power/emergency stop
HNS,Y-FLEX H.PWR
EMG
KLW-M664E-00X Harness No. J0078 1
Harness in duct
Y-axis motor encoder 1
HNS,Y-FLEX Y1P KMK-M66A7-00X Harness No. J0128 1
Harness in duct
Y-axis motor encoder 2
HNS,Y-FLEX Y2P KMK-M66A8-00X Harness No. J0129 1
Harness in duct
X-axis motor encoder
HNS,Y-FLEX XP KMK-M66AF-00X Harness No. J0130 1
Harness in duct
SC-axis motor encoder
HNS,Y-FLEX SCP KMK-M66AA-00X Harness No. J0131 1
Harness in duct
Y-axis motor 1
HNS,Y-FLEX Y1M KLW-M66E4-00X Harness No. J0170 1
Harness in duct
Y-axis motor 2
HNS,Y-FLEX Y2M KLW-M66E5-00X Harness No. J0171 1
Harness in duct
X-axis motor
HNS,Y-FLEX XM KMK-M66EE-00X Harness No. J0172 1
Harness in duct
SC-axis motor
HNS,Y-FLEX SCM KLW-M66E7-00X Harness No. J0173 1
LAN cable in duct HNS,Y-FLEX LAN KLW-M66B2-00X Harness No. J0187 1
Harness in duct
Y-axis DI
HNS,Y-FLEX X DI KMK-M66H4-00X Harness No. J0357 1
Harness in duct
ground wire
HNS,EARTH 90K30-544160 Harness No. J0671 1
Harness in duct
camera wiring
HNS,YB-FLEX CAMERA KLW-M66K0-10X Harness No. J0703 1
DS type
conveyor
unit
W1 standard
conveyor
Conveyor belt pulley PULLEY ASSY. KLW-M913A-A2X 8
*7
Conveyor belt pulley PULLEY,CONV. ASSY. KLW-M914A-A0X 4
*7
Conveyor belt pulley
(tension adjustment)
TENSIONER ASSY. KLW-M913R-A0X 4
*7
