A-17
Appendix
Position Name Part name Part No. Note Qty
Y-axis
Y-axis duct
(YA: right side)
LAN cable in duct HNS,Y-FLEX LAN KMC-M66B2-00 Harness No. J0182
1
Harness in duct
Y-axis DI (limit)
HNS,Y-FLEX Y SAFE KMM-M66F8-00 Harness No. J0259
1
Harness in duct
X-axis DI
HNS,Y-FLEX X DI KMM-M66H4-00 Harness No. J0356
1
Harness in duct
ground wire
HNS,EARTH 90K30-544200 Harness No. J0669
1
Harness in duct
camera wiring
HNS,YA-FLEX CAMERA KMC-M66K0-00 Harness No. J0701
1
Y-axis duct
(YB: left side)
Center tape for
protecting cable
TAPE,Y DUCT 1 KMC-M260B-00
1
Outer periphery tape
for protecting cable
TAPE,Y DUCT 2 KMC-M260C-00
1
Inner periphery tape for
protecting cable
TAPE,Y DUCT 3 KMC-M260D-00
1
Cable mounting plate PLATE, NUT KV7-M2266-00X
2
Cable support bracket BRACKET,HARNESS KHY-M2669-00X
2
Cable duct DUCT,CABLE KMC-M2678-00
1
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J032
8
Mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04010
4
Mounting screw SCREW, PAN HEAD 98502-03004
4
Harness in duct
power/emergency stop
HNS,Y-FLEX H.PWR
EMG
KMC-M664E-00 Harness No. J0078
1
Harness in duct
Y-axis motor encoder 1
HNS,Y-FLEX Y1P KMM-M66A7-00 Harness No. J0128
1
Harness in duct
Y-axis motor encoder 2
HNS,Y-FLEX Y2P KMM-M66A8-00 Harness No. J0129
1
Harness in duct
X-axis motor encoder
HNS,Y-FLEX XP KMM-M66AF-00 Harness No. J0130
1
Harness in duct
SC-axis motor encoder
HNS,Y-FLEX SCP KMM-M66AA-00 Harness No. J0131
1
Harness in duct
Y-axis motor 1
HNS,Y-FLEX Y1M KMC-M66E4-00 Harness No. J0170
1
Harness in duct
Y-axis motor 2
HNS,Y-FLEX Y2M KMC-M66E5-00 Harness No. J0171
1
Harness in duct
X-axis motor
HNS,Y-FLEX XM KMM-M66EE-00 Harness No. J0172
1
Harness in duct
SC-axis motor
HNS,Y-FLEX SCM KMC-M66E7-00 Harness No. J0173
1
LAN cable in duct HNS,Y-FLEX LAN KMC-M66B2-00 Harness No. J0187
1
Harness in duct
Y-axis DI
HNS,Y-FLEX X DI KMM-M66H4-00 Harness No. J0357
1
Harness in duct
ground wire
HNS,EARTH 90K30-544200 Harness No. J0671
1
Harness in duct
camera wiring
HNS,YB-FLEX CAMERA KMC-M66K0-10 Harness No. J0703
1
A-18
Appendix
Position Name Part name Part No. Note Qty
DL type
conveyor
unit
Conveyor belt (DL)
Standard conveyor
Conveyor belt pulley PULLEY,CONV. ASSY. KGY-M9140-A03
16
*7
Conveyor belt pulley PULLEY CONV. ASSY KV7-M9140-A02
4
Conveyor belt (DL)
Both side extended
conveyor
Conveyor belt pulley PULLEY,CONV. ASSY. KGY-M9140-A03
16
*7
Conveyor belt pulley PULLEY CONV. ASSY KV7-M9140-A02
4
Conveyor belt (DL)
One side extended
conveyor
Conveyor belt pulley PULLEY,CONV. ASSY. KGY-M9140-A03
16
*7
Conveyor belt pulley PULLEY CONV. ASSY KV7-M9140-A02
4
*7
Board stopper (DL)
L360 type
Right flow
Main stopper 1-1 CYL.RL CVST1-3 ASSY KMM-M654M-200
1
Main stopper 2-1 CYL.RL CVST2-3 ASSY KMM-M654M-700
1
Sub stopper 1-2 CYL.RL CVST1-2 ASSY KMM-M654M-100
1
Sub stopper 2-2 CYL.RL CVST2-2 ASSY KMM-M654M-600
1
Exit stopper 1 CYL.RL CVST1-5 ASSY KMM-M654M-400
1
Exit stopper 2 CYL.RL CVST2-5 ASSY KMM-M654M-900
1
Speed controller SPEED CONTROLLER KHW-M9274-A00
12
Board stopper (DL)
L360 type
Left flow
Main stopper 1-1 CYL.LR CVST1-3 ASSY KMM-M654N-200
1
Main stopper 2-1 CYL.LR CVST2-3 ASSY KMM-M654N-700
1
Sub stopper 1-2 CYL.LR CVST1-4 ASSY KMM-M654N-300
1
Sub stopper 2-2 CYL.LR CVST2-4 ASSY KMM-M654N-800
1
Exit stopper 1 CYL.LR CVST1-1 ASSY KMM-M654N-000
1
Exit stopper 2 CYL.LR CVST2-1 ASSY KMM-M654N-500
1
Speed controller SPEED CONTROLLER KHW-M9274-A00
12
Board stopper (DL)
L510 type
Right flow
(L810: Option)
Main stopper 1-1 CYL.RL SLCV ST3 ASSY KMK-M653M-200
1
Main stopper 2-1 CYL.RL CVST2-3 ASSY KMM-M654M-700
1
Main stopper 1-2:
L: 810
㎜
(option)
CYL.RL SLCV ST4 ASSY KMK-M653M-300 Option
(1
*9
)
Main stopper 2-2:
L: 810
㎜
(option)
CYL.RL CVST2-4 ASSY KMM-M654M-800 Option
(1
*9
)
Sub stopper 1-1 CYL.RL CVST1-1 ASSY KMM-M654M-000
1
Sub stopper 1-2 CYL.RL CVST1-2 ASSY KMM-M654M-100
1
Sub stopper 2-1 CYL.RL CVST2-1 ASSY KMM-M654M-500
1
Sub stopper 2-2 CYL.RL CVST2-2 ASSY KMM-M654M-600
1
Exit stopper 1 CYL.RL CVST1-5 ASSY KMM-M654M-400
1
Exit stopper 2 CYL.RL CVST2-5 ASSY KMM-M654M-900
1
Speed controller SPEED CONTROLLER KHW-M9274-A00
16(20
*9
)
Board stopper (DL)
L510 type
Left flow
(L810: Option)
Main stopper 1-1 CYL.LR CVST1-3 ASSY KMM-M654N-200
1
Main stopper 2-1 CYL.LR CVST2-3 ASSY KMM-M654N-700
1
Main stopper 1-2:
L: 810
㎜
(option)
CYL.LR CVST1-2 ASSY KMM-M654N-100 Option
(1
*9
)
Main stopper 2-2:
L: 810
㎜
(option)
CYL.LR CVST2-2 ASSY KMM-M654N-600 Option
(1
*9
)
Sub stopper 1-1 CYL.LR CVST1-5 ASSY KMM-M654N-400
1
Sub stopper 1-2 CYL.LR CVST1-4 ASSY KMM-M654N-300
1
Sub stopper 2-1 CYL.LR CVST2-5 ASSY KMM-M654N-900
1
Sub stopper 2-2 CYL.LR CVST2-4 ASSY KMM-M654N-800
1
Exit stopper 1 CYL.LR CVST1-1 ASSY KMM-M654N-000
1
Exit stopper 2 CYL.LR CVST2-1 ASSY KMM-M654N-500
1
Speed controller SPEED CONTROLLER KHW-M9274-A00
16(20
*9
)
A-19
Appendix
Position Name Part name Part No. Note Qty
DL type
conveyor
unit
Board clamp (DL)
L360 type
Cylinder CYLINDER KLT-M9263-001
4
*7
Speed controller SPEED CONTROLLER KLW-M926S-A00
8
*7
Linear guide GUIDE KV7-M9266-010
12
*7
Board clamp (DL)
L510 type
Cylinder CYLINDER KLT-M9263-001
8
*7
Speed controller SPEED CONTROLLER KLW-M926S-A00
16
*7
Linear guide GUIDE KV7-M9266-010
24
*7
DL type
push-up
unit
PU-axis operation
(DL)
Motor drive belt BELT 315-EV3GT-15 RF KHY-M921D-001
2
*8
Lane 1
Bolt screw side belt
BELT 1524-3GT-15 KMC-M921L-000
1
*8
Lane 2
Bolt screw side belt
BELT 1374-3GT-15 KMC-M921M-000
1
*8
Tension pulley shaft SHAFT 1 KHW-M921C-000
2
*8
Tension pulley
mounting circlip
CIRCLIP 99009-1040X
2
*8
Tension pulley bearing BEARING 90933-01J300
4
*8
Motor drive side pulley PULLEY 1:P22-3GT KV7-M9205-010
2
*8
Motor drive side pulley
mounting bolt
BOLT HEX,SOCKET
HEAD
91312-04012
2
*8
Motor drive side pulley
mounting washer
WASHER, PLAIN 90990-28J076
2
*8
Drive unit assembly
pulley
PULLEY:P60-3GT KHW-M9215-001
4
*8
Drive unit assembly
bearing
BEARING 90933-01J007
8
*8
Drive unit assembly
circllip
CIRCLIP 90440-01J090
2
*8
Pulley assembly
bearing
BEARING 90933-01J001
4
*8
Pulley assembly pulley PULLEY:P40-3GT KHW-M9223-001
2
*8
Pulley assembly circlip CIRCLIP 99009-12400
2
*8
Single valve for base
Double solenoid valve SOLENOID VALVE KLW-M8583-00X
For carriage clamp
drive valve assembly
Depend-
ing on type
Solenoid valve VALVE KLW-M91V1-00X
• For carriage clamp
drive valve assembly
• For stopper/clamp
board drive valve
assembly
Electrical parts Up/down stream
signal cable relay for
conveyor I/O board
SPARE RELAY KGA-M6522-20X
13
W1 to W4 axes
battery for information
back up
BATTERY KCA-M53G0-01X
2
*1
Required quantity per head unit
*2
Required quantity per nozzle station
*3
Required quantity per blow station
*4
Required quantity per carriage
*5
Required quantity per bank
*6
Required quantity per X-axis
*7
Required quantity for 2 conveyor rails of fixed and movable sides
*8
Required quantity per L810 mm type (option)
