NC Row 2 - NC in Front of MTC 2/WPC PPW 2te Reihe - PPW vor MTC 2/WPC 61
Always place the modules on a conductive surface (table with an ESD coating, conductive ESD foam,
ESD bag or container).
Do not bring modules near visual display units, monitors or televisions. Keep them at least 10 cm away
from the screen.
1.3.3.4
1.3.3.4 Measurements and Modifications to ESD Modules
Measurements and Modifications to ESD Modules
Measurements of the assemblies may only be taken if
▪ The measuring device has been grounded (e.g. via protective conductor) or
▪ The measuring head of the potential-free measuring device has been briefly discharged before
measurement (e.g. touching blank metal control unit housing).
► Always use an earthed soldering iron if you carry out any soldering work.
1.3.3.5
1.3.3.5 Dispatching ESD Modules
Dispatching ESD Modules
► Always store modules and components in conductive packaging (e.g. metallized plastic bags or met-
al sleeves) and dispatch them in conductive packaging.
► If the packaging is not conductive, place the modules in a conductive envelope before packaging.
Use conductive foam rubber, ESD bags, domestic aluminum foil or paper, for example. NEVER use
plastic bags or film.
► If the module has integral batteries, ensure that the conductive packaging does not touch or short-
circuit the battery terminals and, if necessary, first cover the terminals with insulating tape or mate-
rial.
1.3.4
1.3.4 Release History
Release History
Document
SIPLACE X-Series S
NC row 2 - NC in front of MTC 2/WPC
Assembly instructions
Release Changes
04/2013 First edition
10/2014 Amendments and supplements:
▪ Jumper setting for new nozzle changer
▪ Scope of delivery and parts lists
▪WPC
Introduction
Staff Qualifications and Training 1.3.5 SIPLACE on the World Wide Web (WWW)
62 NC Row 2 - NC in Front of MTC 2/WPC PPW 2te Reihe - PPW vor MTC 2/WPC
1.3.5
1.3.5 SIPLACE on the World Wide Web (WWW)
SIPLACE on the World Wide Web (WWW)
Log into our SIPLACE
®
homepage at http://www.siplace.com.
► You can choose between the German and English versions.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the
SIPLACE User Group
. Here you can call up spe-
cial information about our placement systems e.g.
▪ Technical documentation,
▪ Technical information,
▪ Spare parts lists etc.
Registration for the user group is very simple:
► Click on the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.4
1.4 Staff Qualifications and Training
Staff Qualifications and Training
Qualified or adequately trained personnel means that these people are familiar with the setting up, op-
eration and maintenance of automatic placement systems and add-on devices and are suitably qualified,
e.g.:
▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical
circuits and system components in accordance with normal safety standards.
▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord-
ance with normal safety standards.
▪ Have received first aid training.
1.5
1.5 Abbreviations
Abbreviations
Abbreviations Description
PA, PA1, PA2 Placement area, Placement area 1, Placement area 2
CO Component
COT Changeover table
COT-i Changeover table insert
C&P Collect&Place
CPP Collect&Pick&Place head
CPx Collective term for CPP, CP20, CP12 and/or CP6
ESD Electrostatic sensitive device
EMC Electromagnetic compatibility
PCB Board
MTC Matrix Tray Changer
NC Nozzle changer
WPC Wafflepack changer
Brief Description
2.4.1 Materials for X4i S Product Description
NC Row 2 - NC in Front of MTC 2/WPC PPW 2te Reihe - PPW vor MTC 2/WPC 63
2
2 Brief Description
Brief Description
The relevant upgrade kit extends SIPLACE X-Series S machines by a second row of nozzle changers
for CPP and C&P20 heads as well as TwinHeads.
Machines of types SIPLACE X3 S and X4 S that are equipped with an MTC already have a row of nozzle
changers in front of the MTC.
If these machine types are upgraded with an MTC or WPC later on, the row of nozzle changers has to
be installed as described in this manual.
2.1
2.1 Product Description
Product Description
The second row of nozzle changers extends the relevant machine by an additional four nozzle maga-
zines, thereby increasing its flexibility.
2.2
2.2 Requirements
Requirements
When installing a second row of nozzle changers on machines of type X4i S, the COT insert at the rel-
evant location must be in position 2.
2.3
2.3 Restrictions
Restrictions
Due to longer travel paths, the use of a second row of nozzle changers reduces the placement perfor-
mance.
2.4
2.4 Scope of Delivery
Scope of Delivery
2.4.1
2.4.1 Materials for X4i S
Materials for X4i S
The following parts are needed for each location:
▪ Once for location 2 or 4:
Support option ASP speed flex for row 2 [03090225-xx]
▪ Once for location 1 or 3:
Support option ASP speed flex for row 2 SP1/3 [03097749-xx]
▪ Once per location:
Protective cap assy. [03085665-xx]
▪ Once for location 1 or 3:
Short cover on right [03086067-xx]
▪ Once for location 2 or 4:
Short cover on left [03086070-xx]
▪ Coding sheet box assy. [03084178-xx]
2.4.2
2.4.2 Material for X4 S, X3 S, X2 S
Material for X4 S, X3 S, X2 S
The following parts are needed for each location:
▪ Basic assembly NC row 2/W5 magazine [03089888-xx]
▪ Coding sheet box assy. [03084178-xx]
NOTICE
Outer table position
The COT insert must always be in the outer position.
► In X4i S machines, the COT insert must be moved to the outer position.
► In X4 S, X3 S and X2 S machines, the standard position for the COT insert is already the
outer position.
