Feeder Inspection Unit 2.4 Dimension Gauges for OHP 2.4−4 DX1OEC−12−330−A0 Pneumatic feeder for 12 to 24 mm 12 to 24 mm Pneumatic feeder
2.4 Dimension Gauges for OHP
Feeder Inspection Unit
2.4−3
DX1OEC−12−330−A0
Pneumatic feeder for 8 mm
8mm
Pneumatic feeder
Feeder Inspection Unit
2.4 Dimension Gauges for OHP
2.4−4
DX1OEC−12−330−A0
Pneumatic feeder for 12 to 24 mm
12 to 24 mm
Pneumatic feeder
2.4 Dimension Gauges for OHP
Feeder Inspection Unit
2.4−5
DX1OEC−12−330−A0
Pneumatic feeder for 32 to 72 mm
Delay limit
Advance
limit
32 to 72 mm
Pneumatic feeder
=REMARKS=
Concerning the Pneumatic feeders for 32−72 mm, measure the advance limit on the bottom side
and the delay limit on the top side of the wheel teeth.
