2.4 Dimension Gauges for OHP Feeder Inspection Unit 2.4−5 DX1OEC−12−330−A0 Pneumatic feeder for 32 to 72 mm Delay limit Advance limit 32 to 72 mm Pneumatic feeder =REMARKS= Concerning the Pneumatic feeders for 32−72 mm, …
Feeder Inspection Unit
2.4 Dimension Gauges for OHP
2.4−4
DX1OEC−12−330−A0
Pneumatic feeder for 12 to 24 mm
12 to 24 mm
Pneumatic feeder
2.4 Dimension Gauges for OHP
Feeder Inspection Unit
2.4−5
DX1OEC−12−330−A0
Pneumatic feeder for 32 to 72 mm
Delay limit
Advance
limit
32 to 72 mm
Pneumatic feeder
=REMARKS=
Concerning the Pneumatic feeders for 32−72 mm, measure the advance limit on the bottom side
and the delay limit on the top side of the wheel teeth.
Feeder Inspection Unit
2.4 Dimension Gauges for OHP
2.4−6
DX1OEC−12−330−A0
Pneumatic double feeder for 0603
0603W
Pneumatic double feeder
