5.1 Daily Check Items
Feeder Inspection Unit
5.1−1
DX1OEC−80−070−A0
5.1 Daily Check Items
DX1OEC−80−070−A0
Sentence No.
No. Check item Check method and criteria Frequency
1 Gauge jig
• Ensure that there are no nicks or chip components
adhering to the surface (bottom side) of the gauge jig
or stopper.
At the start of
operation and when
detaching/attaching
gauge jig
2 Clamp stand
• Ensure that chip components are not adhering to the
surface to which feeder of the clamp stand is to be
loaded or air conductor.
Must be free of flaw or deformation due to nick.
• Ensure that there are no foreign matters or chip
components adhering to the clamp roller of the clamp
stand.
At the start of
operation and when
detaching/attaching
tape feeder
3 Camera adjustment
• Checking holding
position
• Set the gauge jig onto the clamp stand and adjust
the camera to the pickup position. Then, while
switching the view select lever between L and R,
check if the camera position is correct.
(Refer to ‘4.1.3’.)
• Adjust the camera position if necessary.
(Refer to ‘5.1.1 Adjusting Camera Position’.)
At the start of
operation
• Check camera
lighting
• Check if the LED is lit and adjust the intensity.
Adjust the intensity of the camera on the monitor as
necessary.
At the start of
operation
