Feeder Inspection Unit SAFETY−1 DX1OEC−03−010−A0 DX1OEC−03−010−A0 Sentence No. Safety Precautions Observe the Instructions It explains of important precautions that must be observed to help operators prevent possible acc…
Feeder Inspection Unit
2
DX1OEC−02−010−A0
5.2 Routine Check Item 5.2−1..........................................
5.2.1 Gauge Jig Precision Check 5.2−2............................................
5.2.2 Replacing LED in the Camera 5.2−3..........................................
5.3 Lubrication 5.3−1..................................................
5.3.1 Guide to Lubrication Table 5.3−1.............................................
5.3.2 Recommended Lubricants 5.3−2.............................................
5.3.3 XYZ Stage 5.3−3..........................................................
5.3.4 Clamp Stand 5.3−5.........................................................
6. TROUBLESHOOTING 6.0−2...........................
6.1 Troubleshooting 6.1−1.............................................
7.RECYCLING 7.0−2....................................
7.1 Synthetic Resin Parts 7.1−1........................................
Feeder Inspection Unit
SAFETY−1
DX1OEC−03−010−A0
DX1OEC−03−010−A0
Sentence No.
Safety Precautions
Observe the Instructions
It explains of important precautions that must be observed to help operators prevent possible accidents
during repair and keep productions after operating.
The level of hazard or damage in consequence of ignoring the instructions is classified as follows.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, may result in death
or serious injury.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury or property damage only
accidents.
NOTICE
NOTICE indicates knowledge necessary to have
or point to be noted for the safety work.
Symbols are classified according to the observed contents.
(The following are an example of hazard alert symbols.)
It indicates ATTENTION ALERT contents.
It indicates PROHIBITION contents.
It indicates COMPULSION contents.
Feeder Inspection Unit
SAFETY−2
DX1OEC−03−010−A0
WARNING
NEVER remodel or repair the
power box.
There is the possibility of
electric shock.
Prohibition
Be sure to ground the
equipment.
There is the possibility of
electric shock.
ATTENTION
Shut OFF air pressure when
touching the movable parts of
tape feeder.
Hands can be pinched by
movable parts.
