5.3 Lubrication Feeder Inspection Unit 5.3−3 DX1OEC−80−140−C0 5.3.3 XYZ Stage 3 4 2 1 4 4 Oiling No. Oiling point Oil type Oil volume Period Lubrication method 1 Feed screw (X) MP grease Moderate amount 3 months Apply gr…
Feeder Inspection Unit
5.3 Lubrication
5.3−2
DX1OEC−80−140−C0
5.3.2 Recommended Lubricants
Sliding Parts
Machine oil Grease
Panasonic
−
*1
MP Grease
*1
MP Grease
−
Shell Tonna Oil T68 Alvania Grease 2 Alvania Grease 2
Alvania EP
Grease R0
Mobil Vactra No.2 Mobilux 2 Mobilux 2 Mobilux EP0
Esso Febis K68
Beacon 2
or
Lithtan 2
Beacon 2
or
Lithtan 2
Pen−O−Led
EP grease
or
Lithtan EP0
Kyodo Yushi − Multemp LRL Multemp LRL −
Application
Examples
Sliding parts Ball screw Chain
*1 The grease is sold through spare parts route.
Parts No.: 1kg can N990PANA−023
100g tube N990PANA−022
80g bellows 5 pcs N990PANA−027
• Use ISO #68 or equivalent for machine oil.
Antirust Lubrication
Name Spare Parts Number Sales Route
Touch Lube N990PANA−028 Panasonic Factory Solutions Co., Ltd.
5.3 Lubrication
Feeder Inspection Unit
5.3−3
DX1OEC−80−140−C0
5.3.3 XYZ Stage
3
4
2
1
4
4
Oiling
No. Oiling point Oil type
Oil
volume
Period Lubrication method
1 Feed screw (X) MP grease
Moderate
amount
3 months
Apply grease entirely to the thread
and wipe off any excess.
2 Feed screw (Y) MP grease
Moderate
amount
3 months
Apply grease entirely to the thread
and wipe off any excess.
3 Feed screw (Z) MP grease
Moderate
amount
3 months
Apply grease entirely to the thread
and wipe off any excess.
4 Bearing MP grease
Moderate
amount
Once a
year
Fill grease appropriately from the
open side and wipe off any excess.
=HINT=
1−4: It is not necessary to disassemble the unit for lubrication.
Feeder Inspection Unit
5.3 Lubrication
5.3−4
DX1OEC−80−140−C0
Feed Screws
• Apply grease entirely to
the thread and wipe off any
excess with a waste cloth.
Thread
Thread
Feed screw (Y)
Feed screw (X)
Feed screw (Z)
T
hread
=HINT=
It is not necessary to disassemble the unit for lubrication.
Bearing
As shown in the drawing below, fill proper amount of oil from the both sides (x 3 points)
Bearing
