1 - 5 S tudent Guide Advanced 1 Edition 02/2005 Course C ontents Advanced Level 1 5 Preventive Maintenance: 0 – Maintenan ce Schedule – Equipment and tools neede d for Maintenance – Mainten ance work e very shift – Maint…
1 - 4
Student Guide
Course Contents Advanced Level 1 Edition 02/2005
4
Calibration(Sitest): 0
– Start / Terminating the SITEST
– Components of the User Interface
– User Interface Displays
– Overview of the machine calibration
– Zero Point Corrections on the C&P and P&P heads
– Carry out the Calibration with single calibration menus
– Complete Machine Calibration
– Check vacuum and adjust air kiss
Siplace Vision (PCB Fiducial): 0
– Overview digital visionsystem
– Illumination for fiducials
– Shape of fiducials
– Synthetic fiducials
– Pattern as fiducials or bad mark
– Synthetic bad mark
1 - 5
Student Guide Advanced 1
Edition 02/2005 Course Contents Advanced Level 1
5
Preventive Maintenance: 0
– Maintenance Schedule
– Equipment and tools needed for Maintenance
– Maintenance work every shift
– Maintenance work every week
– Maintenance work every month
– Maintenance work every 2 month
– Maintenance work every year
– Maintain the sleeves
– Maintain the valve plungers
Troubleshooting: 0
– Check list to start the machine troubleshooting
– Overview of LED's used throughout the machine
– Common machine problems
– Common program related problems
– Testing and monitoring the status of the head board functions
– Threshold values of vacuum check
– Testing Input / Output functions
1 - 6
Student Guide
Course Contents Advanced Level 1 Edition 02/2005
6
Overview available media
Doculist Siplace X-Serie Part number
User Manual Siplace X German
User Manual Siplace X English
Sitest Software description 601.xx, German
Sitest Software description 601.xx English
Preventive Maintenance X, German
Preventive Maintenance X, English
Adjustment Manual Siplace X, German
Adjustment Manual Siplace X, English
Service Manual Siplace X, German
Service Manual Siplace X, English
Circuit diagrams Siplace X, German
Circuit diagrams Siplace X, English
Spare part catalog German
Spare part catalog English
Siplace Axis tester
Preventive Maintenance MTC2, Edition 03/03, German
Preventive Maintenance MTC2, Edition 03/03, English
User‘s Manual MTC 2, Edition 01/04, German
User‘s Manual MTC 2, Edition 01/04, English
Service Manual MTC 2, Edition 03/03 German
Service Manual MTC 2, Edition 03/03 English
Spare part catalog MTC 2, Edition 08/2002
Spare part catalog German
Job Guide Preventive Maintenance, English
Job Guide Set-up of a SIPLACE Line, Edition 09/99, English
SW Version Description Station Software Version 601.xx Ge/En
Installation Software601, German/English
