PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 2: Requirements/Machine Overview Part No. 4005.00.906 2-9 Temperature Monitor Box E-Stop Switch Audible Alarm Type-K Thermocouple Temperature Indicator (PCB) Power Rec…
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 2: Requirements/Machine Overview
Part No. 4005.00.906 2-8
Cleaning Hood (option)
Flow Well
Heater Control (option)
Compliant Arm Locks
Preheater
X-Rail
Handle
Flow Well
Z-Axis
Positioning
Knob
X-Axis Stop
(preheater)
2.6 PCBRM System 5.2 – System Overview
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 2: Requirements/Machine Overview
Part No. 4005.00.906 2-9
Temperature Monitor Box
E-Stop Switch
Audible Alarm
Type-K
Thermocouple
Temperature
Indicator (PCB)
Power
Receptical
Microswitch
Interface
Receptical
Z-Axis Positioning Knob
Microswitch
Interface Plug
Top
Heater Controls
Bottom
Heater Controls
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 2: Requirements/Machine Overview
Part No. 4005.00.906 2-10
Preheater Chassis
Fuses
Y-Axis
Preheater
Lock Knob
Z-Axis Adjust Wheel
Y-Axis Preheater Slides
Heat
Shield
(Main)
