1 Introduction/Overview

1.0 Welcome

Please read this User’s Guide carefully before initial set-up of the PCBRM15 or PCBRM System 5.2 to

insure the optimal start-up and maintenance of the equipment. This User’s Guide has been compiled in

accordance with ISO 9000 and the EC machine guideline regulations. It contains all information and

instructions that are necessary for safe and trouble-free operation of the PCBRM15 and PCBRM

System 5.2. Considerable time has been spent in an attempt to provide in-depth instructions in regards

to the unpacking, installation, verification, operation and maintenance of these systems.

1.1 PCBRM15 and PCBRM System 5.2 Overview

The PCBRM15 and PCBRM System 5.2 machines provide lead-free selective soldering and rework of

through-hole components and thermally challenging assemblies The PCBRM System 5.2 adds a 6500

watt preheater.

1.2 Contacts & Support

Air-Vac is always willing to assist our customers with any technical or operating questions. If you have

any questions on machine parameters, correct nozzle requirements, options, procedures or

maintenance, please do not hesitate to call.

Air-Vac Engineering Company, Inc.

30 Progress Avenue, Seymour, CT 06483

Tel: 203-888-9900 - Fax: 203-888-1145

http://www.air-vac-eng.com/

General Sales, Tooling Information and Technical Support: airvac@air-vac-eng.com

PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview

Part No. 4005.00.906 1-4

1.3 Warranty

Air-Vac Engineering Company warrants its equipment for a period of one (1) year from date of shipment on all

parts, materials and labor costs required to repair the system except for component parts that are considered

“wear and tear” items which are warranted for ninety (90) days. These include, but are not limited to, heaters,

belts, lights, vacuum cups and tubing.

Air-Vac agrees to repair or replace any or all such equipment that may prove to be defective within the warranty

period, without expense, excluding shipping to the owner. This warranty shall not apply to any products that have

been repaired or altered except by Air-Vac Engineering.

Services under warranty shall not affect an extension of the warranty period, nor will a new warranty period be

granted for the parts, which were replaced/repaired. The title of the replaced parts will automatically pass to Air-

Vac.

Air-Vac reserves the right to reject replacement under this warranty where, in the sole opinion of Air-Vac, the

defect is due to obvious misuse and/or improper maintenance of the module or any part thereof.

The express and/or implied warranty of Air-Vac is limited to the replacement and/or repair of any item defective in

material and/or workmanship. Other damages, if any, direct or consequential are expressly excluded from this

warranty.

Air-Vac shall be liable under this warranty only if 1) Air-Vac receives notice during the appropriate warranty period

(90 days or 1 year as applicable); 2) The products are operated in accordance with the supplied documentation;

and 3) Such products are, to Air-Vac’s satisfaction, determined to be defective.

When contacting Air-Vac for warranty inquiries, please provide the following information:

Order number which the parts were shipped

Model and serial number of the product

Reason for warranty

Products cannot be returned to Air-Vac without authorization – please call for an RMA #.
