3.1 Overview
Fig. 3.1.1 Overview - Placement functions
Placement functions
Execute wafflepack changer functions
Display and vibrate linear feeders
Display magazine and change inventory levels
Omit components
Display and fill empty tracks
Display general errors
Display transport errors
Display machine errors
Display track errors
Display set-up for location 4
Display set-up for location 3
Display set-up for location 2
Display set-up for location 1
From flow chart 2.3.2
Feeders
Errors
Set-up
