7. Setup 7.1. I/O Test
7. Setup
7. Setup
7.1. I/O 测试
设置窗口里的数码输入栏里确认 port 输入状态.可确认输出 port 的限制级状态.个 port 的输入,输出状
态确认..
参考
참고
手册 [检测软件构造] - [使用者环境] – [数码输入窗口] 参考
매뉴얼 [검사 프로그램 구조] - [사용자 환경] – [디지털 입출력 설정 창] 참고
7.1.1. 输入 port
参考
(*) 进行方向 右左时.
部分功能根据设备型号会有不操作现象.
DEV1
NO
名称
说明
确认
1
IN1 (*OUT2)
PCB 感应 IN1
感应器触碰
2
PSTP Up
Pre stopper upper 感应
Solenoid 操作
3
IN2 (*OUT1)
PCB 感应 IN2
感应器触碰
4
PSTP Down
Pre-Table stopper down 感应器
Solenoid 操作
5
W1 (*W3)
PCB 感应 W1
感应器触碰
6
WSTP Up
Work-Table stopper upper 感应
Solenoid 操作
7
W2
PCB 感应 W2(Load 减速感应)
感应器触碰
8
WSTP Down
Work-Table stopper down 感应
Solenoid 操作
9
W3 (W1)
PCB 感应 W3
感应器触碰
10
PUP1 Up
Pushup plate1(Clamp) Upper 感应器
Solenoid 操作
11
OUT1 (IN2)
PCB 感应 OUT1
感应器触碰
12
PUP2 Up
Pushup plate2(Clamp) Upper 感应器
Solenoid 操作
13
OUT2 (IN1)
PCB 感应 OUT2
感应器触碰
14
Safety Left
Left Safety sensor
感应器触碰
15
TIN2
TAD-10/ IN2
TAD-10
16
Safety Right
Right Safety sensor
感应器触碰
17
Under Door
Under door 感应器
Door 开关
7. Setup 7.1. I/O Test
18
Board Available
SMEMA (Receive from pre machine)
Conveyor
19
Emergency
Emergency switch
Switch 操作
20
Not busy
SMEMA (Receive from Next machine)
Conveyor
21
Barcode Trigger
外部条码枪 Trigger 代码
Barcode
22
TIN1
TAD-10/ IN1
TAD-10
23
N.NG signal
N.NG signal feed-back from 7700 series
Conveyor
24
Upper door
Upper door 感应器
Door 开关
25
Air press
气压感应器
Gage 显示
26
P.OK signal
P.OK signal feed-back
Conveyor
27
Reset
Reset switch
Switch 操作
28
N.BA signal
N.BA signal feed-back
Conveyor
29
Completed
轨道操作结束
Conveyor
30
Error Conveyor
轨道操作失败
Conveyor
31
Insert Busy
PCB 从前段设备进入当中
Conveyor
32
Remove Busy
PCB 从下一个阶段设备进入当中
Conveyor
7. Setup 7.1. I/O Test
7.1.2. 输出
参考
备注栏 Conveyor 标记时 Conveyor controller 里会排除.
DEV1
NO
名称
说明
备注
1
TL (Top)
Tower Lamp (Top)
灭灯与否
2
3
TL (Middle)
Tower Lamp (Middle)
灭灯与否
4
5
TL (bottom)
Tower Lamp (Bottom)
灭灯与否
6
Not busy
SMEMA (Send to pre machine)
Conveyor
7
Buzzer
Buzzer (Alarm)
声音
8
Board Available
SMEMA (Send to next machine)
Conveyor
9
PSTP
Pre stopperUp/Down
Solenoid 动作
10
11
WSTP
Work stopper Up/Down
Conveyor
12
NG signal
SMEMA (Send to next machine)
Conveyor
13
PCB PUP
Pushup plate Up/Down
Conveyor
14
15
PCB BUP
Backup pin Up/Down
Conveyor
16
17
STB1 CH1
Strobe1 channel 1
3D 照明
18
STB1 CH2
Strobe1 channel 2
3D 照明
19
STB1 CH3
Strobe1 channel 3
3D 照明
20
STB1 CH4
Strobe1 channel 4
3D 照明
21
STB1 PW1
Strobe1 Duration 1
3D 照明
22
STB1 PW2
Strobe1 Duration 2
3D 照明
23
STB1 PW3
Strobe1 Duration 3
3D 照明
24
STB1 PW4
Strobe1 Duration 4
3D 照明
25
STB1 PW5
Strobe1 Duration 5
3D 照明
26
STB1 PW6
Strobe1 Duration 6
3D 照明
27
28
TOUT1
TAD-10/ OUT1
TAD-10
29
TOUT2
TAD-10/ OUT2
TAD-10
30
Reset TAD-10
TAD-10 硬件初始化
TAD-10
31
Safety ENB
Safety 感应器动作 有/无
32
