6 Parts Replacement

6.1 Overview

This section includes parts replacement instructions and information for ordering recommended spares

and replacement parts for your dispensing system. This section contains the following procedures:

•

art

s Or

deri

ng Infor

atio

•

Unpackin

g and Insp

ect

g Re

placemen

arts

•

Warran

•

Cleanin

g and Inspe

ction

•

Credi

t and

chang

•

cord

eping

WARNING!

Parts replacement should only be performed by a trained service technician.

Asymtek assumes no liability for personal injury or property damage that may

occur as a result of spare parts being replaced by a non-certified technician.

6.2 Safety First

Operation of the dispensing system involves heat, air pressure, electrical power, mechanical devices, and

the use of hazardous materials. It is essential that every person servicing or operating the dispensing

system fully understands all hazards, risks, and safety precautions. Refer to Section 2 – Safety in this

manual and to the Forte Dispensing System Installation, Operations, and Maintenance Manual for

important safety information.

WARNING!

Perform a service shutdown before replacing parts. Servicing electrical,

pneumatic, or hydraulic components or assemblies that make de-energizing the

whole system impractical, should only be performed by trained personnel. There

should always be a second person present when servicing a system under power.

WARNING!

DO NOT hot swap connections when working with electrical and pneumatic power

supplies. Turn the main circuit break off before disconnecting the external power

plug from the facility.

ForteMAXDispensingSystemAddendum Parts Replacement

6.3 Parts Ordering Information

6.3.1 Placing Your Order

Customers can order spare parts by contacting Asymtek Customer Service. Contact information is listed

at the front of this manual. Spare parts can also be ordered online through our Internet Web Store. To set

up a web store account, send an email to americas.es.cs@nordson.com.

NOTE

This section does not include the removal and replacement of dispensing valve

components. Refer to the applicable valve manual for instructions.

When ordering parts, be prepared to provide the following information:

•

Your C

ompany N

ame

•

Billing Addr

ess

•

hip

ping A

ress

•

Part

Number an

d Des

ption

•

Purchas

e Or

der

Num

ber

•

Quantity

• Dispensing System Serial Number

(foun

d o

back

panel)

• Shipping Instructions with Collect Account

Number

6.3.2 Shipping Instructions

When ordering parts, specify which carrier you prefer to use and provide your shipping account number. If

no instructions are received, Asymtek will determine the best shipping method and items will be shipped

prepaid with the shipping charge added to the invoice.

6.4 Warranty

Contact Asymtek Technical Support for any warranty issues pertaining to spare parts. Wear items and

consumables are covered under warranty against manufacturer defect only. Expected lifetimes for these

parts will vary based upon application and use.

Consumable parts are generally considered as parts that are replaced on a frequency of > 1 per calendar

year under expected regular usage. In most cases, these parts are “wetted parts” that make contact with

the dispensed fluid. Wear items are those items that have been identified to have limited life expectancy

(less than 5 years) but are not considered consumables. Wear items are often highly application

dependent, high user-touch, or adjusted parts.

6.5 Credit and Exchanges

Contact Asymtek Customer Service for credit or exchanges of recommended spare parts or refurbished

components (components restored to original specifications but not sold as new).

6.5.1 Return Material Authorization

Contact Asymtek Technical Support to obtain a Return Material Authorization (RMA) before returning any

parts.

NOTE

Find your local Technical Support contact on the Asymtek web page,

www.nordsonasymtek.com.

6.6 Record Keeping

The type of service performed should be recorded in the dispensing system maintenance records. Dates,

part numbers/serial numbers of replaced parts, names of technicians, and other pertinent data should be

recorded.

ForteMAXDispensingSystemAddendum Parts Replacement

6.7 Unpacking and Inspecting Replacement Parts

Replacement parts are shipped to distributor or customer facilities in individual shipping cartons. Review

the packing slip to ensure that the correct parts were received. Contact Asymtek Technical Support if any

discrepancies are discovered.

Before unpacking your spare parts, visually inspect the carton for damage. If applicable, check the tip

sensors for indications of improper shipping and handling. Inform the freight carrier of any damage.

6.8 Cleaning and Inspection

Always clean the area made visible after a failed part is removed from the dispensing system. Inspect the

area for signs of what may have caused the part to fail. This may help prevent future part damage. When

removing parts that will be reinstalled, visually inspect them for damage. If found undamaged, retain them

for reinstallation. Replace damaged parts and hardware as appropriate.

6.9 Spare Parts List

This section contains a list of item numbers corresponding to the part description. Review the spare parts

kits Excel file for the item number referencing the part number when ordering replacements parts for the

Forte MAX Dispensing System. Contact Asymtek Technical Support for questions.

Table 6-1 Spare Parts List

Descript

ion

1 ASSY, NANO CAMERA & LIGHT, RGB

SCREW, M3 X 0.5 SOCKET X 8

PWA, LED DRIVER 1.25A

CABLE, RGB PWA TO 5CH CT ADAPTR

SPRING, LEAF

CABLE TIE, 4", BLACK

WASHER, FLAT M3

SCREW M3X0.5 SOCKET X 4

SCREW, M4 X 0.7, SOCKET CAP, X8

BRKT, LASER COVER, M-EPSILON1420

SCREW, M3X6 BUTTON HEAD

COVER, QUARTZ, LHS, SHIELD, 32mm

ASSY, uEPSILON LHS, ILD1420(203)

LABEL, 3"X1"

CABLE TIE, 4", BLACK

SCREW, M4X0.7, BUTTON HEAD, X8

TUBING, 170ID X .250OD, POLYURE

ASSY, SCALE W ELEC, LEFT

SCREW, M4X0.7 BUTTON HEAD, X6

TOOL, BREEZE SHIELD LID LEVEL

SCREW, M6 X 1.0 SOCKET X 12

SCREW, M4X0.7X10MM, BUT HD, SS

FERRITE, SNAP-ON, 10MM DIA

WIRE MARKERS DISPENSER

BD, FORTE ELECTRICAL

LICENSE, ACRONIS IMAGE DEPLOY
