ForteMAXDispensingSystemAddendum Parts Replacement
© 2023 Nordson Corporation 67
I
t
e
m
N
u
m
b
e
r
Descript
ion
72 INSERT, TOP, O-RING, S-920
73 ASSY, S-9XX 4MM BELT PULLEY
74 ASSY, STOP PIN, S-9XX
75 KIT, DISP, STN COMMON PARTS
76 ASSY, RAIL EXT.SET, 4MM BELT
77 SCREW, M4X0.7 SOCKET FLAT X 12
78 SCREW, M4 X 0.7, SOCKET X 10
79 SENSOR, BOARD, LOW PROFILE
80 RETAINER, BELT, CMP
81 BELT, FLAT 3.6X1.4X2340, ESD
82 INSERT, TOP, O-RING, S-920
83 ASSY, S-9XX 4MM BELT PULLEY
84 ASSY, STOP PIN, S-9XX
85 KIT, DISP, STN COMMON PARTS
86 ASSY, RAIL EXT.SET, 4MM BELT
87 SCREW, M4X0.7 SOCKET FLAT X 12
88 SCREW, M3X.05 FLAT
89 RETAINER, BELT, CMP
90 INSERT, TOP, FLAT BLT, CHAIN, S920
91 ASSY, S-9XX 6MM BELT PULLEY
92 BELT, FLAT, 5.7X1.4X1350, ESD
93 KIT, DISP, STN COMMON PARTS
94 SCREW, M4X0.7 SOCKET FLAT X 12
95 SCREW, M4 X 0.7, SOCKET X 10
96 SCREW, M3X.05 FLAT
97 SENSOR, BOARD, LOW PROFILE
98 RETAINER, BELT, CMP
99 INSERT, TOP, FLAT BLT, CHAIN, S920
100 ASSY, S-9XX 6MM BELT PULLEY
101 BELT, FLAT, 5.7X1.4X1850
102 ASSY, STOP PIN, S-9XX
103 ASSY, RAIL EXT. SET, 6MM BELT
104 KIT, DISP, STN COMMON PARTS
105 SCREW, M4X0.7 SOCKET FLAT X 12
106 SCREW, M4 X 0.7, SOCKET X 10
107 SCREW, M3X.05 FLAT
108 SENSOR, BOARD, LOW PROFILE
109 RETAINER, BELT, CMP
110 INSERT, TOP, FLAT BLT, CHAIN, S920
111 ASSY, S-9XX 6MM BELT PULLEY
112 BELT, FLAT, 5.7X1.4X2350
113 ASSY, STOP PIN, S-9XX
114 ASSY, RAIL EXT. SET, 6MM BELT
115 KIT, DISP, STN COMMON PARTS
ForteMAXDispensingSystemAddendum Parts Replacement
68 © 2023 Nordson Corporation
I
t
e
m
N
u
m
b
e
r
Descript
ion
116 FTG, ELB-3, 1/4MNPT X 3/8
117 FITTING, 1/8 FPT X .170 BARB
118 PLUG, QUICK DISCONNECT, 3/8
119 TAPE, PTFE-1/4"
120 FITTING, ELBOW, 1/4PX3/8T, BRAS
121 TUBING, PU, CLR 3/8"OD 1/4"ID
122 FITTING, ELBOW, 1/8NPT-1/4TUBE
123 SCREW, M4 X 0.7, SOCKET CAP, X8
124 SCREW, M4X0.7X25MM SHCS, SS
125 FITTING,1/8NPT X DUAL-Y 1/4OD
126 ASSY, CNV PN.PNL, NO MANUAL FLOW
127 PANEL, IMPNGMNT & TOOLING AIR
128 TUBING, 170ID X .250OD, POLYURE
129 REGULATOR 0-100 PSI 0-6.8 BAR
130 ELBOW, 3/8 TUBE X 1/8 MNPT
131 GAUGE, 0-100 PSI/KPA
132 NUT, M4, W/LOCKWASHER, ZPL-ST
133 LABEL, SELF LAMINATING 1X2.25"
134 COVER PLATE, 36MM SQ HOLE
135 FITTING, TUBE, MALE 3/8"X1/4"NPT
136 PLUG, DOME .750 DIA.
137 FITTING, TEE, 1/4 FNPT
138 VALVE, 2-WAY SHUT OFF
139 FTG, ELB-3, 1/4MNPT X 3/8
140 FITTING, 1/8 FPT X .170 BARB
141 PLUG, QUICK DISCONNECT, 3/8
142 TAPE, PTFE-1/4"
143 FITTING, ELBOW, 1/4PX3/8T, BRAS
144 FLOWMETER, GAS, .4-4SCFM
145 TUBING, PU, CLR 3/8"OD 1/4"ID
146 FITTING, ELBOW, 1/8NPT-1/4TUBE
147 SCREW, M4 X 0.7, SOCKET CAP, X8
148 SCREW, M4X0.7X25MM SHCS, SS
149 FITTING, 1/8NPT X DUAL-Y 1/4OD
150 PANEL, IMPNGMNT & TOOLING AIR
151 ASSY, CNV PN.PNL., MANUAL FLOW
152 TUBING, 170ID X .250OD, POLYURE
153 REGULATOR 0-100 PSI 0-6.8 BAR
154 ELBOW, 3/8 TUBE X 1/8 MNPT
155 GAUGE, 0-100 PSI/KPA
156 NUT, M4, W/LOCKWASHER, ZPL-ST
157 LABEL, SELF LAMINATING 1X2.25"
158 COVER PLATE, 36MM SQ HOLE
159 FITTING, TUBE, MALE 3/8"X1/4"NPT
160 FITTING, FEM QR, HI TEMP, 1/4"OD
ForteMAXDispensingSystemAddendum Parts Replacement
© 2023 Nordson Corporation 69
I
t
e
m
N
u
m
b
e
r
Descript
ion
161 CLAMP, STEPLESS HOSE 7/16"
162 ELBOW, 1/4MNPTX1/4Q-DISC, SWIV
163 FITTING, 1/4"Y, QUIK-DISCON.
164 SCREW, M4X0.7, BUTTON HEAD, X8
165 REGULATOR, E/P, 0-130PSI, 0-5V
166 BRKT, EP REG. FLUID 2
167 MUFFLER, 1/8 MPT
168 TUBING, 170ID X .250OD, POLYURE
169 SOCKET, MICROFIT, 20-24G, 5A, 30G
170 PLUG-M, 4S, MICROFIT, 3mm DUAL
171 CABLE TIE, NYLONG, RED
172 LABEL, SELF LAMINATING 1X2.25"
173 LABEL, BLANK, COMPONENT
174 HEAT SHRINK, 1/4", 3X, BLACK
175 CLIP, WIRE HARNESS
176 SCREW, M4 X 0.7, SOCKET CAP, X8
177 SCREW, M4X0.7, BUTTON HEAD, X8
178 ASSY, FORTE MAX BRACKET
179 KIT, FORTE MAX PLATFORM UPGRADE
180 UK, FORTE MAX, EXT. PITCH-112MM
181 KIT, KLUBER GREASE, FORTE MAX
182 TEST ASSY, Z-GAP, S2-9XX
183 CABLE TIE, 4", BLACK
184 ASSY, MONOCLE, NANO, 0.5X, FORTE
185 SCREW, M4X0.7 BUTTON HEAD, X6
186 SCREW, M4X0.7 SOCKET FLAT X 10
187 SCREW, M4X0.7 SOCKET FLAT X 10
188 TIE WRAP, 5.5" BLACK
189 CABLE, 48V PWR, SII VISION
190 PCA, 5CH LIGHT DRIVER V2 TESTED
191 CABLE TIE, 4", BLACK
192 ASSY, MONOCLE, NANO, 1.0X, FORTE
193 SCREW, M4X0.7 BUTTON HEAD, X6
194 SCREW, M4X0.7 SOCKET FLAT X 10
195 SCREW, M4X0.7 SOCKET FLAT X 10
196 TIE WRAP, 5.5" BLACK
197 CABLE, 48V PWR, SII VISION
198 PCA, 5CH LIGHT DRIVER V2 TESTED
199 ASSY, CAMERA&LIGHT, RED SQUARE-OFF, FORTE
200 ASSY, STOP PIN, STRAIGHT, UNDRBD, TOPMOUNT
201 PWA, LED DRIVER 1.25A
202 KIT, LIGHTSOURCE ADAPTER, S2-900
203 LICENSE, ACRONIS IMAGE DEPLOY
204 USB, ACRONIS SNAP DEPLOY TOOL
