Section 1 Introduction
1-1 What is a Tracker 2800?
A Huntron Tracker 2800 is a troubleshooting instrument that is used manually to troubleshoot printed
circuit boards to the component level. Throughout this manual it will be referred to as the Tracker 2800
or 2800S (where applicable). This instrument uses a troubleshooting technique called Analog
Signature Analysis (ASA) for applying a current limited sine-wave voltage to an un-powered circuit or
electronic component. The resulting Current (I) and Voltage (V) characteristic (analog Signature) is
then displayed and used for comparing known good signatures of a good circuit card or electronic
component to those of a suspect circuit board. This comparison allows you to troubleshoot circuit cards
and electronic components without applying external power or requiring circuit cards to “start up”.
Each pin of a component can have a unique signature. When components fail, their signatures change
so troubleshooting using ASA is simply a matter of finding the defective component by analyzing its
signature. The Tracker 2800 implements the ASA technique of troubleshooting.
The built-in current limited stimulus sine-wave of the Tracker 2800 ensures non-destructive testing and
does not damage any components. ASA has many advantages as a proven, fast, and effective
troubleshooting technique.
You can:
Troubleshoot circuitry that cannot be powered up due to a shorted condition.
Troubleshoot in a qualitative mode, allowing you to see physical problems with a suspect component.
Compare device characteristics with known types for better matching.
Investigate intermittent problems by seeing marginal indicators, such as small amounts of leakage,
noise, etc.
Eliminate risk of accidental shorting across other points during POWER ON testing which could
further damage the component or other components on the board.
Minimize the risk of shock hazard since the ASA troubleshooting approach requires no power applied
to the circuitry.
Perform preventative maintenance by seeing flaws in components that could possibly lead to untimely
failures.
Look at replacement components before they are installed in circuitry to reduce the risk of installing
defective ones.

6
ASA may be universally applied to any type of passive component like a resistor, capacitor, or
inductor, or a solid state semiconductor component like a diode, transistor, SCR, digital, analog, or
mixed-signal IC. When troubleshooting a circuit card, the resultant signature is a composite of various
component signatures at a particular node in the circuitry. By understanding what different signatures
mean, you can determine which components are faulty.
You can manually connect the Tracker 2800 front panel test terminals directly to the circuit card or
component that you are testing. You can automate the test process to a certain degree by connecting to
boards under test via custom cabling or IC clip cables using a Tracker 2800S. The Tracker 2800S is a
modified version of the Tracker 2800 that has internal switch cards and external, front panel IDC
connectors to which custom cable interfaces or DIP clip cables can be connected.
1-2 Specifications
Electrical (Note: Test Signal is a sine wave.) Specifications subject to change without
notice
Open Circuit Voltage (Vs):
6
selections of peak voltage:
200mV,
3V, 5V, 10V, 15V, 20V
Source Resistance (Rs):
9
selections of resistance:
10Ω, 50Ω, 100Ω, 500Ω, 1kΩ, 5kΩ, 10kΩ,
50kΩ, 100kΩ
Short circuit current (Vs divided by Rs)
Maximum
200 mApk
Frequency (fs):
6
selections of frequency:
20Hz
, 50Hz, 60Hz,
200Hz, 500Hz, 2kHz
Channels
Number
2
Connections
Banana (Channel A, Common, Channel B);
Two (Ch. A and Ch. B) 40 pin IDC connectors (Tracker
2800S only)
Overvoltage Protection
Circuit breaker
Auxiliary Connection
9 pin mini jack with ground, Trigger IN, Trigger OUT,
Calibration TP, Sine wave zero-crossing, Signal ON, Line
IN and Line OUT
DC Voltage Source
0
-
10VDC + output @ 200mA max;
PC Interface
USB 2.0
GENERAL
Power Requirements
100/115V~ 0.2A 50/60Hz, 230V~ 0.1A 50Hz
Fuse
T400mA 5x20mm 250V
Operating Temperature
59 degrees F to 86 degrees F
(+15 degrees C to +30 degrees C)
Storage Temperature
-
58 degrees F to 140 degrees F

7
(
-
50 degrees C to +60 degrees C)
Humidity
0 to 50%
R.H.
Dimensions
11.1" W x 4.4" H x 8.5” D (28.2cm W x 11.2cm H x
22.1cm D
)
Warranty
1 year limited
Supplied Accessories
Huntron P/N QTY Description
06-5217 1 User's Manual CD
98-0043 2 Test Lead Black
98-0249 1 pair Huntron Microprobes MP20
98-0265 1 Power cord
98-0284 1 Shrouded blue test lead
1-3 Safety Information (Information sur la sécurité )
Symbols and Warnings: (Symboles et avertissements):
The following symbols are used either in this manual or on the unit:
Les symboles suivants sont utilisés soit dans ce manuel ou sur l'appareil:
Protective Ground (Earth) Terminal. Do not disconnect any protective ground
wires.
Rez de protection (terre). Ne débranchez pas de câbles de garde protectie.
CAUTION This symbol is used in the user’s manual as a warning that improper use could
result in unit malfunctioning. For your safety always follow the instructions next to the
symbol on the unit and in the manual.
ATTENTION Ce symbole est utilisé dans le manuel de l'utilisateur comme un avertissement que
l'usage abusif peut entraîner des dysfonctionnements unité. Pour votre sécurité toujours suivre les
instructions à côté du symbole de l'unité et dans le manuel.
The Huntron Tracker 2800 conforms to the following Standards:
