4022 593 51431 选件手册 07.01 供料器服务店 5-59 维修 TTF 图 5-7
选件手册 4022 593 51431
5-58 供料器服务店 07.01
维修 TTF
5.8 管理
5.8.1 管理过程
] 在修理过程中每完成一个步骤，都填写此表。
] 它可用于管理目的。
5.8.2 管理表
Inspection
A
ssembleon Feeder Repair Twin Tape Feeder
1. Visual Inspection
Reel Holder Reel Clamp Top Foil Unit Transport Roll present
Disk Cam Brake Nozzle Catch Movement Nozzle Catch UL
Buffers Buffer Arm movement Movement Nozzle Catch LL
Buffer Rollers present Peel-Off Unit Movement Handle
Complete Lever Guide Wire Spring present
Interface Contact Pins presen
t
Remarks:
2. Administration Feeder Number & Upper Lane & Lower Lane Counter & Software Version (note on other side)
3. Functional Test 1: 5. Functional Test 2:
Upper Lane Lower Lane Upper Lane Lower Lane
1 Control board EEPROM parameters 1 Control board EEPROM parameters
2 Power supply Power supply current 2 Power supply Power supply current
3 Select/busy line Internal wiring 3 Select/busy line Internal wiring
4 External connection 4 External connection
5 Human interface Backward button 5 Human interface Backward button
6 Forward Button 6 Forward Button
7 Lane Button 7 Lane Button
8LEDs8LEDs
9 Pull handle Lock / unlock 9 Pull handle Lock / unlock
10 Configuration switches Remote switch 10 Configuration switches Remote switch
11 Local mode pitch switch - - 11 Local mode pitch switch - -
12 Peeloff unit Motor current - - 12 Peeloff unit Motor current - -
13 Buffer sensors - - 13 Buffer sensors - -
14 Nozzle detections LED current - - 14 Nozzle detections LED current - -
15 Index unit Motor current forward - - 15 Index unit Motor current forward - -
16 Sprocket wheel Tooth sequence - - 16 Sprocket wheel Tooth sequence - -
17 Min / max tooth pitch - - 17 Min / max tooth pitch - -
18 Min / max tooth width - - 18 Min / max tooth width - -
4. Repair Feeder
5. Repeat Functional Test, Fill in Test 2.
6. Fill in corrective actions and replaced parts on next sheet
OK NOK
7. Calibrate feeder - -
8. Pack feeder
TTF Corrections
PA 2657/00
Work-order number: - Counter Upper Lane: Date
Feeder number: - Counter Lower Lane: SW Ver
Repair number - RMA Number
1. Parts
Description: Quantity: Description: Quantity: Description: Quantity:
A Nozzle Catch Assy LL - V Lever UL Assy - J Peel-off-unit Compleet -
B Nozzle Catch Assy UL - W Lever LL Assy - Peel-Off Handle Assy -
C Sprocket Wheel Assy - R Guide Block TTF - Peel-Off Module Assy Kunstof -
D Contact Block Assy - Y Buffer Tension Spring - Peel-Off Motor Assy (motor) -
E Cable Assy - O Human Interface TTF - K Inductive Sensor D3 TTF -
F Lever Guide Assy - P Assy Micro Switch - L Print Controller TTF -
G Top Foil Unit TTF - Q Top Plate - M Print Nozzle Catch -
H Reel Clamp One Sided - N Print Procket Senso
r
-
I Sprocket Motor TTF - U Middle Plate TTF -
S Rotating Arm Long (UL) -
T Lower Reel Holder -
2. Operations / Actions
Description Applicable
Load new software version -
Adjust Index sensor LL -
Adjust Index sensor UL -
Clean Feeder -
Calibrate Feeder -
Adjust Switch Block -
3. Delivery settings
Description
Set switches for delivery settings
-
-
-
-
-
- -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
NOKNOK
-
Ẕ
Ẕ
