4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-13
Module Number: 3-15 Module Name: Topfoil Peel-off Assembly
REMARK: The complete topfoil peel-off assembly will be delivered without rotation lock 15-151 and fastening item 15-153.
Quantity per module
8 12 16 24 32 44 56 Feeder width (mm)
Item No.
Part of
item No. Ordering code
Description
PA2654/0y
PA2645/1y
PA2654/2y
PA2654/3y
PA2654/4y
PA2654/5y
PA2654/6y
PA number of feeder width
Module Number: 3-15 Module Name: Topfoil Peel-off Assembly Remarks
3-15 - 5322 693 11521 Complete Assembly 1111111Only for PA2654/x6 and older. The complete topfoil peel-off assembly will be
delivered without rotation lock 15-151 and fastening item 15-153
4 9498 396 01166 Top foil guide assy R2 1
Only for PA2654/x5
5 9498 396 01152 Top foil guide assy R3 1
Only for PA2654/x6
15-1 3-15 5322 693 11522 Pivot press unit (pinion) 1111111Only for PA2654/x6 and older, only together with part 5322-535-10574
15-1 9498 396 00985 Pivot press unit (pinion) 1111111
Intended for PA2654/x7, can also be used on PA2654/x6 and older but only in
together with part 9498 396 00986
15-3
3-15
5322 466 12223 Peel-off front plate 1111111
15-4
3-15
4022 516 05922 Lock/unlock knob 1111111
15-5 3-15 5322 535 10574 Main shaft (pinion) 1111111Only for PA2654/x6 and older, only together with part 5322-693-11522
15-5 9498 396 00986 Main shaft (pinion) 1111111
Intended for PA2654/x7, can also be used on PA2654/x6 and older but only in
together with part 9498 396 00985
15-6
3-15
5322 361 11113 Topfoil peel-off motor 1111111
15-7 3-15 5322 502 14493 Csk Stl St M2x4 1111111For PA2654/x6 and older quantity per module is 2, standard packing unit: 10
15-8
3-15
5322 535 14139 Dowel 1.5x8 1111111
15-10
3-15
5322 492 11752 Compression spring 1111111
Standard packing unit: 10
15-151
3-15
5322 417 11408 Rotation lock 1111111
15-152
3-15
4822 502 11674 Pan scr Stl St M2x5 1111111
Standard packing unit: 5
15-153 3-15 5322 502 21211 Pan scr Stl St M3x5 1111111For PA2654/x6 and older quantity per module is 2, standard packing unit: 25
Spare Parts Lists ITF 3-14
Module Number: 4 Module Name: Clamping Lever Assembly
27
4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-15
Module Number: 4 Module Name: Clamping Lever Assembly
Quantity per module
8 12 16 24 32 44 56 Feeder width (mm)
Item No.
Part of
item No. Ordering code
Description
PA2654/0y
PA2645/1y
PA2654/2y
PA2654/3y
PA2654/4y
PA2654/5y
PA2654/6y
PA number of feeder width
Module Number: 4 Module Name: Clamping Lever Assembly Remarks
16
4
5322 401 11769 Clamping unit assy. (8 mm) 1 1
Including items 16-7 and 16-8
16
4
5322 401 11771 Clamping unit assy. (12mm) 1
Including items 16-7 and 16-8
16
4
5322 401 11772 Clamping unit assy. (16mm) 1
Including items 16-7 and 16-8
16
4
5322 401 11773 Clamping unit assy. (32mm) 1
Including items 16-7 and 16-8
16
4
5322 401 11774 Clamping unit assy. (44mm) 1
Including items 16-7 and 16-8
16
4
5322 401 11775 Clamping unit assy.(56 mm 1
Including items 16-7 and 16-8
16-7
16
5322 256 10546 Cable holder (8&24mm) 1 1
16-7
16
5322 256 10569 Cable holder (12mm) 1
16-7
16
5322 256 10568 Cable holder (16mm) 1
16-7
16
5322 256 10567 Cable holder (32mm) 1
16-7
16
5322 256 10566 Cable holder (44mm) 1
16-7
16
5322 256 10571 Cable holder (56mm) 1
16-8
16
4822 530 70123 Retain ring for cable holder 1111111
Standard packing unit: 10
113
4
5322 502 21213 Pan schr St Zn M3x12 2
Standard packing unit: 25
141
4
5322 502 14155 Pan schr St Zn M3x16 2
Standard packing unit: 10
161
4
5322 502 14405 Pan schr St Zn M3x8 2 2 2
Standard packing unit: 25
363
4
5322 502 21212 Pan schr St Zn M3x10 2 2
Standard packing unit: 25
23
4
5322 320 12489 Cable assembly 1111111
231
23
4822 502 10004 Set screw M2x4 1111111
Standard packing unit: 10
25
4
5322 277 11816 Microswitch assembly 1111111
252
4
5322 502 21322 Pan schr St Zn M2x8 2222222
Standard packing unit: 10
26
4
5322 402 11168 Handle assembly 1111111
Excluding items 261/262/263/264/265/266/267
261
4
5322 528 11281 Roller 1111111
262
4
5322 256 10545 Spring bolt 1111111
263
4
5322 492 11729 Spring handle 0.4x36.6 1111111
Standard packing unit: 10
264
4
5322 529 10416 Dowel Ø3h6x8 1111111
Standard packing unit:
265
4
5322 529 10415 Dowel Ø2h6x12 1111111
Standard packing unit:
266 4 5322 502 21212 Pan schr St Zn M3x10 1111111For PA2654/x6 and older quantity per module is 3, standard packing unit: 25
267
4
5322 529 10417 Dowel Ø2h6x8 1111111
Standard packing unit:
27
4
9498 396 00877 Handle assembly 1111111
