Option Manual 4022 593 51431 3-2 Feeder Service Shop 07.01 Spare P arts ITF & TTF Feeders
4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-1
Spare Parts ITF & TTF Feeders
CHAPTER 3 Spare Parts ITF & TTF Feeders
3.1 Module Overview Spare Parts ITF
The spare parts detailed in CHAPTER 3.3 are divided into the following modules:
Module 1: Control Unit
Module 2-22: Reel Holder Assembly
Module 3-15: Topfoil Peel-off Assembly
Module 4: Clamping Lever Assembly
Module 5: Sprocket Wheel Drive Assembly
Module 6: Mounting Plate Assembly
3.2 Repair
Local Repair:
For approximately 90% of the parts it is possible to repair the feeder locally without
the need of special equipment. However, not all parts are mentioned in the
following pages. The parts mentioned here are the parts likely to get damaged or
lost during production or repair actions.
Central Repair:
a) Assembléon offers central repair if local repair is not possible.
b) Central repair comes with the following conditions:
• Feeder must be packed properly. Damage caused by transport will not be
repaired
• Feeders must be complete. No parts should be missing.
Customized Repair:
With customized repair, the feeder will be returned to the originator with the
shortest possible repair time. The feeder will be functionally repaired and all
customer improvements, identifications will remain untouched (unless it is noticed
that this has negative influence on the feeder performance). Customized repair is
cheaper than Swap Repair.
Swap Repair:
This is refurbished repair. Within the delivery agreements of the regions, a defective
feeder is replaced by a refurbished feeder. All customized improvements, identifi-
cations are removed from these feeders. The feeders represent a correct functioning
feeder of the same level as the corresponding PA#. The contents of these feeders is
exactly as the contents of the PA#.
Feeders returned for Customized and Swap repair can be returned via regular
channels.
4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-3
Spare Parts ITF & TTF Feeders
3.3 Spare Parts Lists ITF
The fields in the spare parts list have the following meaning:
Item No.: Position Identification.
Part of Item No.: Module the part belongs to.
Ordering Code: The order code at Assembléon.
Description: Description of the article.
Quantity per module: The quantity of the part in one module. Because this
manual covers all ITF feeders, all separate widths and
versions are mentioned.
Width and version is indicated by the PA number of the
feeder (see also see FIGURE 3-1):
•First four digits of PA number indicate the type of feeder
(intelligent tape feeder).
•Second to last digit of PA number indicates the width of
the feeder.
•Last digit of PA number indicates the version of the
feeder.
The PA number can be located according to see FIGURE 3-1.
Remarks: 1.Comment or specific information.
2.Standard Packing Unit: Minimum packing quantity
received at ordering.
FIGURE 3-1
Location of
sticker
Ty pe
Art. No
Feeder No
PA2654/xy
0 = Release 1
5 = Release 2
6 = Release 3
7 = Release 4
0 = 8 mm
1 = 12 mm
2 = 16 mm
3 = 24 mm
4 = 32 mm
5 = 44 mm
6 = 56 mm
2654 = ITF 2
(Intelligent tape
feeder)
