4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-21
Module Number: 6 (continued) Module Name: Mounting Plate Assembly
Quantity per module
8 12 16 24 32 44 56 Feeder width (mm)
Item No.
Part of
item No. Ordering code
Description
PA2654/0y
PA2645/1y
PA2654/2y
PA2654/3y
PA2654/4y
PA2654/5y
PA2654/6y
PA number of feeder width
Module Number: 6 Mounting Plate Assembly Remarks
24
6
5322 693 11526 Position unit, bottom16mm 1
24
6
5322 693 11529 Position unit, bottom 32mm 1
24
6
5322 693 11532 Position unit, bottom 44mm 1
24
6
5322 693 11534 Position unit, bottom 56mm 1
121
6
5322 502 14405 Pan schr St Zn M3x8 4
Standard packing unit: 25
121
6
5322 502 21212 Pan schr St Zn M3x10 4 4
Standard packing unit: 10
121
6
5322 502 21213 Pan schr St Zn M3x12 4 4 4
Standard packing unit: 25
121
6
5322 502 14155 Pan schr St Zn M3x16 4
Standard packing unit: 10
141
6
5322 502 21212 Pan schr St Zn M3x10 2 2 2
Standard packing unit: 25
141
6
5322 502 21213 Pan schr St Zn M3x12 2 2
Standard packing unit: 25
141
6
5322 502 14616 Pan schr St Zn M3x14 2
Standard packing unit: 5
141
6
5322 502 14155 Pan schr St Zn M3x16 2
Standard packing unit: 10
181
6
5322 132 00103 Transmitting sensor 8mm 1
181
6
5322 132 00105 Transmitting sensor 12mm 1
181
6
5322 132 00107 Transmitting sensor 16mm 1
181
6
5322 132 00109 Transmitting sensor 24mm 1
181
6
5322 132 00112 Transmitting sensor 32mm 1
181
6
5322 132 00114 Transmitting sensor 44mm 1
181
6
5322 132 00116 Transmitting sensor 56mm 1
182
6
5322 442 01858 Transmitting cover 8mm 1
182
6
5322 442 01857 Transmitting cover12mm 1
182
6
5322 442 01856 Transmitting cover16mm 1
182
6
5322 442 01855 Transmitting cover24mm 1
182
6
5322 442 01854 Transmitting cover32mm 1
182
6
5322 442 01853 Transmitting cover44mm 1
182
6
5322 442 01852 Transmitting cover56mm 1
191
6
5322 502 21211 Pan schr St Zn M3x5 2
Standard packing unit: 25
191
6
5322 502 14405 Pan schr St Zn M3x8 2
Standard packing unit: 25
191
6
5322 502 21212 Pan schr St Zn M3x10 2
Standard packing unit: 25
191
6
5322 502 14616 Pan schr St Zn M3x14 2
Standard packing unit: 5
191
6
5322 502 14155 Pan schr St Zn M3x16 2
Standard packing unit: 10
191
6
5322 502 14618 Pan schr St Zn M3x20 2 2
Standard packing unit: 5
Spare Parts Lists ITF 3-22
Module Number: 6 (continued) Module Name: Mounting Plate Assembly
6-14 (assy)
141
12121
24
275273
274
272
13
14-3
332
384
341
333
332
331
333
301
302
390
181
400
358
394
401
295
293
351
358
393
394
20-1
20-3
361
392
294
292
291
6-20(assy)
20-2
296
193
192
281 (12-56mm)
281 (8mm)
282
191
194
17-2
17-1
17
271
276
182
313
402
20-4
4022 593 51431 Option Manual
07.01 Feeder Service Shop 3-23
Module Number: 6 (continued) Module Name: Mounting Plate Assembly
Quantity per module
8 12 16 24 32 44 56 Feeder width (mm)
Item No.
Part of
item No. Ordering code
Description
PA2654/0y
PA2645/1y
PA2654/2y
PA2654/3y
PA2654/4y
PA2654/5y
PA2654/6y
PA number of feeder width
Module Number: 6 Mounting Plate Assembly Remarks
192
6
5322 132 00104 Receiving sensor 8mm 1
192
6
5322 132 00106 Receiving sensor 12mm 1
192
6
5322 132 00108 Receiving sensor 16mm 1
192
6
5322 132 00111 Receiving sensor 24mm 1
192
6
5322 132 00113 Receiving sensor 32mm 1
192
6
5322 132 00115 Receiving sensor 44mm 1
192
6
5322 132 00117 Receiving sensor 56mm 1
193
6
5322 442 01859 Receiving cover 8mm 1
193
6
5322 442 01861 Receiving cover 12mm 1
193
6
5322 442 01862 Receiving cover 16mm 1
193
6
5322 442 01863 Receiving cover 24mm 1
193
6
5322 442 01864 Receiving cover 32mm 1
193
6
5322 442 01865 Receiving cover 44mm 1
193
6
5322 442 01866 Receiving cover 56mm 1
194
6
5322 442 01871 Screening plate 8mm 1
194
6
5322 442 01872 Screening plate 12mm 1
194
6
5322 442 01873 Screening plate 16mm 1
194
6
5322 442 01874 Screening plate 24mm 1
194
6
5322 442 01875 Screening plate 32mm 1
194
6
5322 442 01876 Screening plate 44mm 1
194
6
5322 442 01877 Screening plate 56mm 1
271
6
9498 396 01154 Cover + spring 8mm 1
271
6
5322 442 01527 Cover 8mm 1
271
6
9498 396 00374 Cover 12-24mm 1 1 1
271
6
9498 396 00994 Cover 24mm 1
Only for project feeder 9466 920 10731
271
6
5322 442 01532 Cover 32mm 1
Only for PA2654/x6 and older
271
6
5322 442 01533 Cover 44-56mm 1 1
Only for PA2654/x6 and older
271
6
9498 396 00995 Cover 32-56mm 1 1 1
Only for PA2654/x7 and newer
272
6
4022 516 05180 Distance bush 12 8
272
6
4022 516 05190 Distance bush 16 8
272
6
4022 516 05200 Distance bush 24 8
