3 Technical data and assemblies User manual SIPLACE X-Series 3.10 Component trolley From software version 706.1 SP1 Version 10/2014 214 3.10.3 T echnical dat a 3 3 Length x width 727 x 592 mm² 752 x 592 mm² with waste co…
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 706.1 SP1 Version 10/2014 3.10 Component trolley
213
3.10.2 Description
In the standard version, the tape reel container (item 3 in fig. 3.10 - 3) holds tape reels up to a size
of 17" (432 mm).
There are two 5 mm wide gaps on the left and right, between the tape container and the compo-
nent trolley (item. 4 in fig. 3.10 - 3
, page 212) for holding setup lists.
The pullout waste tape container can be found beneath the chassis (item 5 in fig. 3.10 - 3
, page
212
). The cut waste tape travel down a chute into the waste tape container, which must be emp-
tied as it fills up.
The handles (item 6 in fig. 3.10 - 3
, page 212) can be folded up or down.
3
PLEASE NOTE
All component trolleys must be docked onto the
machine in order to operate it.
Fill any free locations with dummy feeder modules as described in
section 2.6.6
, page 94.
3 Technical data and assemblies User manual SIPLACE X-Series
3.10 Component trolley From software version 706.1 SP1 Version 10/2014
214
3.10.3 Technical data
3
3
Length x width 727 x 592 mm²
752 x 592 mm² with waste container
Height of the changeover table 890 mm for 900 mm PCB conveyor height
920 mm for 930 mm PCB conveyor height
940 mm for 950 mm PCB conveyor height
PCB conveyor height 900 mm ± 15 mm (option)
930 mm ± 15 mm (standard)
950 mm ± 15 mm (SMEMA option)
Height of handles when folded out 969 mm
Number of locations 40 (8 mm X tape feeder module)
Weight
Without feeder modules
With feeder module at all locations
80.4 kg
139.6 kg
Tape reel diameter
Standard
Maximum
Up to 432 mm (17")
483 mm (19")
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 706.1 SP1 Version 10/2014 3.10 Component trolley
215
3.10.4 Fiducials on the SIPLACE X-Series component trolley
3
Fig. 3.10 - 4 Fiducials on the SIPLACE X-Series component trolley
(1) Fiducials on the component trolley
Once the SIPLACE X-Series component trolley has been docked in, the machine measures the
fiducials on the component trolley.
For components with an edge length of less than 0.5 mm, i.e. 0402 components and smaller, the
position of the component is determined with the tape pocket before the first component is picked
up.
