User manual SIPLACE X-Series 6 Station extensions From software version 706.1 SP1 Version 10/2014 6.10 3D coplanarity la ser module 395 6.10 3D coplanarity laser module Item no. 519807-xx 3-D coplan, X2 S / X3 S / X4 S 6…
6 Station extensions User manual SIPLACE X-Series
6.9 SIPLACE High-Force Head From software version 706.1 SP1 Version 10/2014
394
6.9 SIPLACE High-Force Head
Item no. 00119736-xx High-Force Head
This item number only applies when ordering a new placement machine with a high force
head instead of a standard TwinStar. 6
6.9.1 Description
The SIPLACE high force head is an advanced development of the standard TwinStar. It can pro-
cess the same component range and also offers the possibility of achieving set-down forces up to
30 N. The SIPLACE high force head can use all the same nozzles and grippers as the standard
TwinStar.
6.9.2 Technical data
6
Al other technical data are identical for the TwinStar and high force head (see section 3.5.7.2,
page 156
).
Programmable set-down force 2.0 N to 10 N ± 10 %
greater than 10 N up to 30 N ± 15 %
User manual SIPLACE X-Series 6 Station extensions
From software version 706.1 SP1 Version 10/2014 6.10 3D coplanarity laser module
395
6.10 3D coplanarity laser module
Item no. 519807-xx 3-D coplan, X2 S / X3 S / X4 S
6.10.1 Safety instructions for coplanarity module sensor
The sensor works with a semiconductor laser which has a wave length of 670 nm (visible/red).
The maximum optical output is 1 mW.
This sensor is classified as laser class 2.
– When using the sensor, always observe the applicable VDE 0837 regulations regarding "Ra-
diation safety of laser devices" and the"Laser radiation" (BGV B2) accident prevention regu-
lation applicable in Germany.
– Also observe the accident prevention regulations of your own country!
The following labels are attached to the front and back of the sensor:
6
Fig. 6.10 - 1 Laser class 2 classification for the sensor
Despite the low laser output, avoid looking directly at the laser beam. As the beam is visible, the
natural reflex of your eyelids will protect your eyes from the beam.
6
WARNING
The housing of the optical sensor may only be opened by authorized personnel.
For repair and service work, always send the sensors to ASM Assembly Systems
GmbH&Co.KG.
6 Station extensions User manual SIPLACE X-Series
6.10 3D coplanarity laser module From software version 706.1 SP1 Version 10/2014
396
6.10.2 Description
The 3D coplanarity laser module works with a line of laser light. This enables you to generate and
analyze the height profile of a two-dimensional arrangement of component leads e.g. BGA, QFP
etc. This analysis provides data about the coplanarity (contact plane) and collinearity (contact line
straightness) of component leads or balls.
6
Fig. 6.10 - 2 3D coplanarity laser module
