User manual SIPLACE X-Series 1 Introduction From software version 706.1 SP1 Version 10/2014 1.6 Important notes on the user manual 41 1.6.5.2 SIPLACE on the World W ide W eb (WWW) We also have our own site on the Interne…
1 Introduction User manual SIPLACE X-Series
1.6 Important notes on the user manual From software version 706.1 SP1 Version 10/2014
40
1.6.4 Revision table
1
1.6.5 Further information about and contents of the documentation package
1.6.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems GmbH&Co.KG
Rupert-Mayer-Str. 44
81379 Munich 1
Edition Amendments
03/2013 EN First edition
10/2013 EN Station software SC 707.0
SIPLACE X4 S micron / X4i S micron
SIPLACE X2 S
SIPLACE SpeedStar - variant M (C&P 20 M)
Component camera, type 41
04/2014 EN Station software SC 707.1
SIPLACE SpeedStar - variant P (C&P 20 P) with nozzle changer
Waffle pack changer (WPC5/WPC6)
SIPLACE JTF-S/JTF-M
03015 placement
SIPLACE X4 S micron / X4i S micron with SIPLACE MultiStar (CPP)
New options
10/2014 EN New sales numbers for machine types
SIPLACE SmartFeeder 8 mm X
Universal nozzle changer for SIPLACE CPx
User manual SIPLACE X-Series 1 Introduction
From software version 706.1 SP1 Version 10/2014 1.6 Important notes on the user manual
41
1.6.5.2 SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log onto our SIPLACE home page at
http://www.siplace.com
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
1 Introduction User manual SIPLACE X-Series
1.6 Important notes on the user manual From software version 706.1 SP1 Version 10/2014
42
1.6.5.3 Documentation packages
The documentation package SIPLACE X-Series, SC 706.1 SP1, version 10/2014 is available in
the following languages:
1
1
Package contents Language
*a
Item no.
DVD product documentation incl. parts catalogue
(PDF and HTML), German + English
Detailed circuit diagrams folder (SIPLACE X-Se-
ries),
German + English
User manual (SIPLACE X-Series) in the ordered
language version
Maintenance manual (SIPLACE X-Series) in the or-
dered language version
JobGuides / JobPoster in the ordered language ver-
sion
Angle gauge / tape gauge in the ordered language
version
German 00197064-02
English 00197065-02
French 00197066-02
Spanish 00197068-02
Portuguese 00197069-02
Hungarian 00197070-02
Czech 00197071-02
Polish 00197073-02
Estonian 00197074-02
Romanian 00197083-02
Finnish 00197075-02
Swedish 00197076-02
Danish 00197077-02
S. Chinese 00197079-02
Korean 00197080-02
*)a Other languages can be realized on request.
PLEASE NOTE
Further information
For further information about the station extensions described in chapter 6
, including the
assembly, operating and maintenance instructions, refer to the SIPLACE homepage.
