User manual SIPLACE X-Series 5 Working with the machine From software version 706.1 SP1 Version 10/2014 5.15 Docking the component trolley in or out 323 5 Fig. 5.15 - 1 Safety instructions for docking the component troll…
5 Working with the machine User manual SIPLACE X-Series
5.15 Docking the component trolley in or out From software version 706.1 SP1 Version 10/2014
322
5.15 Docking the component trolley in or out
5.15.1 Safety instructions for docking component trolleys in and out
Also follow the safety instructions given in section 2.5.11, page 78.
5
In addition, the component trolley can only be docked in if the protective
covers are closed.
There is a button at each location (1,2,3 and 4). The safety concept for the component trolley
changeover specifies that the operator should push this button at the relevant machine location,
to dock or undock the component trolley.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
User manual SIPLACE X-Series 5 Working with the machine
From software version 706.1 SP1 Version 10/2014 5.15 Docking the component trolley in or out
323
5
Fig. 5.15 - 1 Safety instructions for docking the component trolley in or out (example of SIPLACE X2 S / X3 S / X4 S
shown)
In addition, the component trolley can only be docked in if the protective
covers are closed.
(1) Button for docking and undocking the component trolley at location 1
(T) Direction of PCB transport
(1)
5 Working with the machine User manual SIPLACE X-Series
5.15 Docking the component trolley in or out From software version 706.1 SP1 Version 10/2014
324
5.15.2 Docking out the component trolley
Press the button on the respective machine location until the component trolley is completely
undocked.
Swivel the two handles up (item 1 in fig. 5.15 - 2).
5
Fig. 5.15 - 2 Component trolley - swivel handles up to push
With both hands on the handles, pull the component trolley out of the machine.
5.15.3 Safety instructions for moving the component trolley
5
Always hold the handles with both hands when you want to move the component trolley.
Remember that a component trolley with the full complement of feeder modules can tip over
sideways or forward on gradients of 20° or more.
Make sure that the surface on which the trolley is moved has a significantly smaller gradient.
Be careful not to collide with obstacles. The trolley could tip forward if it is traveling fast
enough.
WARNING
Avoid accidents!
To prevent accidents, ALWAYS follow the rules listed below when you move the compo-
nent trolley.
