2 1. Advanced Model 2-9 Specifications V9071iW External Dimensions and Panel Cut-out Dimensions 133.4 +0.5 -0 187.2 +0.5 -0 60.3 201.6 147.6 186.2 132.4 53.1 7.2 Side view Panel cut-out dimensions Rear view Botto…
2-8 1. Advanced Model
V9100iW External Dimensions and Panel Cut-out Dimensions
+
-
256.0
182.0
278.5
198.5
47.2
6.0
257.0
183.0
53.2
+0.5
-0
+0.5
-0
Side view
Panel cut-out dimensions
Rear view
Bottom view
(Unit: mm)
Front view
2-10 1. Advanced Model
V9070iW External Dimensions and Panel Cut-out Dimensions
133.4
+0.5
-0
187.2
+0.5
-0
59.1
201.6
147.6
186.2
132.4
53.1
6.0
Side view
Panel cut-out dimensions
Rear view
Bottom view
(Unit: mm)
Front view
