2-30 3. Lite Model V9080iCD External Dimensions and Panel Cut-out Dimensions 165.5 +0.5 -0 220.5 +0.5 -0 48.9 235.0 180.0 219.5 164.5 42.9 6.0  Panel cut-out dimensions  Bottom view (Unit: mm)  Side view  Rear view …

100%1 / 122
2
3. Lite Model 2-29
Specifications
V9100iC External Dimensions and Panel Cut-out Dimensions
288.0
215.2
303.8
231.0
48.0
6.0
289.0
216.2
54.0
+0.5
-0
+0.5
-0
Side view
Panel cut-out dimensions
Rear view
Bottom view
(Unit: mm)
Front view
2-30 3. Lite Model
V9080iCD External Dimensions and Panel Cut-out Dimensions
165.5
+0.5
-0
220.5
+0.5
-0
48.9
235.0
180.0
219.5
164.5
42.9
6.0
Panel cut-out dimensions
Bottom view
(Unit: mm)
Side view Rear view
Front view
2
3. Lite Model 2-31
Specifications
V9060iTD External Dimensions and Panel Cut-out Dimensions
131.0
+0.5
-0
174.0
+0.5
-0
53.0
182.5
138.8
173.0
130.0
47.0
6.0
Panel cut-out dimensions
Bottom view
(Unit: mm)
Side view Rear view
Front view
