2-20 2. Standard Model
V9120iS External Dimensions and Panel Cut-out Dimensions
312.0
245.2
327.8
261.0
47.9
7.0
313.0
246.2
54.9
+0.5
-0
+0.5
-0
Side view
Panel cut-out dimensions
Rear view
Bottom view
(Unit: mm)
Front view
2
2. Standard Model 2-21
Specifications
V9100iS External Dimensions and Panel Cut-out Dimensions
288.0
215.2
303.8
231.0
48.0
6.0
289.0
216.2
54.0
+0.5
-0
+0.5
-0
Side view
Panel cut-out dimensions
Rear view
Bottom view
(Unit: mm)
Front view
2-22 2. Standard Model
V91080iSD External Dimensions and Panel Cut-out Dimensions
165.5
+0.5
-0
220.5
+0.5
-0
48.9
235.0
180.0
219.5
164.5
42.9
6.0
Panel cut-out dimensions
Bottom view
(Unit: mm)
Side view Rear view
Front view
