User manual SIPLACE Wafer System (SWS) 2 Operational safety
Edition 04/2018 2.2 Warning labels on the SIPLACE Wafer System
39
2
Fig. 2.2 - 2 Warning labels on the SWS - view from back
W201, item no. 03009338-01
W204, item no. 03009343-01
W206, item no. 03009345-01
W210, item no. 03009350-01
W 210
W 201
W 206
W 204
2 Operational safety User manual SIPLACE Wafer System (SWS)
2.2 Warning labels on the SIPLACE Wafer System Edition 04/2018
40
2.2.2 Warning labels
2.2.2.1 Warning label W201
2
W201 in fig. 2.2 - 1, page 38 and fig. 2.2 - 2, page 39, item no. 03009338-01 (quantity per SWS: 2)
2.2.2.2 Warning label W204
2
W204 in fig. 2.2 - 1, page 38 and fig. 2.2 - 2, page 39, item no. 03009343-01 (quantity per SWS: 8)
2.2.2.3 Warning label W206
2
W206 in fig. 2.2 - 2, page 39, item no. 03009345-01 (quantity per SWS: 1)
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
SAFE OPERATION OF THE MACHINE
Safe operation of the machine depends absolutely on the opera-
tor being familiar with the user manual and safety instructions
and putting them into effect.
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the machine while it is running!
DANGEROUS VOLTAGES!
The labeled parts are still live when the main power switch is off
and the mains plug has been disconnected.
Disconnect the machine from the mains before servicing it.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
User manual SIPLACE Wafer System (SWS) 2 Operational safety
Edition 04/2018 2.2 Warning labels on the SIPLACE Wafer System
41
2.2.2.4 Warning label W210
2
W210 in fig. 2.2 - 2, page 39, item no. 03009350-01 (quantity per SWS: 1)
2
W209 in fig. 2.2 - 2, page 39, item no. 03009349-01 (quantity per SWS:1
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button
2
2
2
2
2
2
For Australia, Canada, Mexico and USA, warn-
ing label W209 is affixed to the EMERGENCY
STOP buttons instead of the yellow ring.
