2 Everything you will need for maintenance SIPLACE D1 / D2
02/2010 EN Edition
10
2 Everything you will need for
maintenance
The following lists of materials contain all the tools, equipment and consumables that you will need
to maintain the placement machine. 2
Always use ethyl alcohol for cleaning – do not use solvents. 2
Apply all lubricants sparingly and exactly where they are needed. 2
2.1 Tools and equipment
Have the following tools and equipment to hand before you start the maintenance: 2
Tools and equipment From item number
Waste bin
Vacuum cleaner
Drip tray
Brush
Short-bristled brush
Scissors
Set of hexagon socket spanners
Set of slotted-head screwdrivers
Laboratory gloves
Metal drill bit, 1.1 mm diameter 00092020-01
Metal drill bit, 1.4 mm diameter 00092026-01
Oilstone/whetstone
Grease gun 00366174-01
Universal head stand 00363290-01
SIPLACE D1 / D2 2 Everything you will need for maintenance
02/2010 EN Edition
11
2.2 Consumables
Have the following consumables to hand before you start the maintenance: 2
2.3 Wearing parts
Have the following wearing parts to hand before you start the maintenance: 2
Consumables From item number
Protective latex gloves 00372972-01
Soft, lint-free cloths
Cottonwool buds, lint-free 00352931-02
Microtips medium precision applicators (cottonwool buds) 03020860S01
SIPLACE cleaning tissue 00315253-02
Lens cleaning cloth
Ethyl alcohol
ISOFLEX TOPAS, NCA 52 00328369-01 1 kg can,
00330850-01 50g tube
UNISILKON L250L 00310259S01
WD40, 400 ml 00325833-01
Z axis oil dispenser with Structovis GHD 00367071-01
Fin Grease spray grease (aerosol) 03020782-01
Wearing parts From item number
Modulair 112 G 1/2 inch filter
new version
old version (for 00329906-01 only)
00349311S01
00336902S01
Y-axis cover air filter for 120mm fan 03053286-02
Filter insert, 5 microm. for series 112 00355386-01
Silencer for the Collect&Place head DLM2 (HS-60) 03003134S01
O-ring for valve plunger 00345127-01
Set of valve plungers 00351498-03
Set of cleaned ceramic nozzles or new nozzles
Damping cylinder for protective cover 00334359-01
Grease nipple (1 pack = 8x) 00366104-01
Z axis toothed belt 00334936S01
2 Everything you will need for maintenance SIPLACE D1 / D2
02/2010 EN Edition
12
2.4 Spare parts
Have the following spare parts to hand before you start the maintenance: 2
Vacuum distributor 00319827S02
O-ring, turning station 00320043S01
Toothed belt, turning station 00320041S01
Suction plate for ball catch, complete (10 x) 00354244S01
O-ring for distributor 8*1 NBR 70 B 00201179S01
Star brake for star, complete 03001653S01
O-ring, Venturi nozzle
O-ring, 10*1.5 NBR 70 B
O-ring, 14*1.5 NBR 70 B
O-ring, 8*1 Viton 75
O-ring, 10*1 Viton 75
00320047S01
00320048S01
00350661S01
00350662S01
Vacuum nozzle, 1.5 dia.
Vacuum nozzle, 1.0 dia.
00319420S03
00319423S02
Wearing parts From item number
Spare parts From item number
Y-axis cover air filter for 120mm fan 03053286-02
S50 pneumatic system 00329906-03
Schmersal switch for head crash guard 00338005-01
Set of sleeves (type 12) 00116143S01
Set of sleeves (type 6) 00116114S01
Individual sleeve (type 12) 00350588S02
Individual sleeve (type 6) 00352957S02
Vacuum generator, complete, DLM 2 03003236S01
