SIPLACE D1 / D2 2 Everything you will need for maintenance

02/2010 EN Edition

2 months

Inspect or replace the filter cartridge Drip tray,

Phillips screwdriver,

New filter cartridge, if required

Vacuum, replace the Y-cooling filter mats, if required New filter mat, if required

Inspect or replace the silencer New silencer, if necessary

Clean the sleeve and nozzle seat on the TwinHead Teflon spray, lint-free cloth

Maintain the component feeder table (S feeder modules) Vacuum cleaner, whetstone,

scissors, lint-free cloths, WD40

4 months

C&P 6 / 12 placement head

Z axis

Remove dirt from the toothed belt Brush

Clean the rollers, toothed wheels and toothed belt Lint-free cloths

Check the toothed belt for wear

Grease the toothed belt Short-bristled brush, ISOFLEX

TOPAS NCA 52

Check the Z axis guide

Check the jaws and the ball race for damage

Oil the Z-axis ball race Oil dispenser with Structovis

GHD

Star / distributor plate

Wipe the star and the vacuum distributor plate Lint-free cloths

Apply film of grease to running surface of the star

brake ISOFLEX TOPAS, NCA 52

Segments

Clean the segments Ethyl alcohol, cottonwool buds

Remove dirt from around the segments

Ethyl alcohol, cottonwool buds

Valve casing

Clean the valve casings and their environment

Ethyl alcohol, cottonwool

buds

Vacuum distributor

Clean and grease the O-rings UNISILKON L250L

Check the vacuum distributor for damage

Wipe the vacuum distributor Ethyl alcohol, lint-free cloth

Blow air through the vacuum distributor Compressed air

Check that the ball catches run easily

Interval Location Equipment/spare parts Done (date)

2 Everything you will need for maintenance SIPLACE D1 / D2

02/2010 EN Edition

4 months

Star brake

Check the star brake for damage and to ensure it is

working correctly

Wipe the star brake / remove grease Lint-free cloth

Fill the holes with grease ISOFLEX TOPAS, NCA 52

Apply film of grease to surface of the star brake ISOFLEX TOPAS, NCA 52

Vacuum distributor seat

Clean the vacuum distributor seat Ethyl alcohol, lint-free cloth

Valve adjustment drives

Wipe the valve adjustment drives Lint-free cloth

Clean the locating disk and the gap

Lint-free cloth

Clean the ball bearings Lint-free cloth

Check that the ball bearings are working correctly

Remove visible dirt

Turning station

Clean the locating disk

Wipe the black O-ring Ethyl alcohol, lint-free cloth

Check the O-ring for damage

Check the toothed belt for damage

Clean the stop surfaces

Vacuum generator

Clean the Venturi nozzles Ethyl alcohol, lint-free cloth

Blow air through Venturi nozzles Compressed air

Grease the O-rings UNISILKON L250L

Clean and blow air through the vacuum generator

block

Ethyl alcohol, cottonwool

buds

Silencer

Clean holes to the Venturi nozzles

Ethyl alcohol, cottonwool

buds

Check for dirt

Check the plastic mount for breaks

Year

Vacuum beneath the lifting table Vacuum cleaner

Clean and preserve the PCB conveyor SIPLACE cleaning tissue

Interval Location Equipment/spare parts Done (date)

SIPLACE D1 / D2 2 Everything you will need for maintenance

02/2010 EN Edition

Year

Greasing the Y-axis gantries Grease nipple, grease gun, if

required, ISOFLEX TOPAS NCA

Function test of used tape cutter

Check the hood switches and the emergency-stop buttons

Check the protective covers New damping cylinder if neces-

sary

Clean the gas spring, if required Lint-free cloths

Clean the protective covers Lint-free cloths

Pick&Place module

Clean /check additional volume filter Compressed air

Clean the scale Ethyl alcohol, lint-free cloth

Interval Location Equipment/spare parts Done (date)

Sleeves / valve plungers

Sleeves

Check the film

Grease the anti-rotation element Fin Grease spray grease,

Microtips cottonwool buds

Check the switching ring

Clean the longitudinal vacuum hole Metal drill bit, 1.4 mm

Clean the transverse vacuum hole Metal drill bit, 1.1 mm

Check the suction plate New suction plate, if required

Clean the suction plate Lint-free cloth

Clean the edge of the sleeve Ethyl alcohol, lint-free cloth

Clean the incremental disk Ethyl alcohol, lint-free cloth

Clean the sleeve shaft Ethyl alcohol, lint-free cloth

Clean the circumference of the ball catch Ethyl alcohol,

lint-free cottonwool buds

Valve plunger

Wipe the valve plunger with a dry cloth Lint-free cloth

Check the sealing lips, the spring O-ring and the sleeve
