Issue 2, Mar 18

Open cover and scan required

equipment

equipment verification should not be

possible due to different equipment

description

Kill DEK software. Edit values in

"ItacVerificationItems.xml" file

according to equipment

description of new equipment used

on activated WO. Start DEK

software, initialize machine, open

cover and scan required

equipment and material.

All equipment and material should

be verified (green tick)

Check iTAC server on TR \ MIS -

Work order \ Order

scanned material should be setup

on the line and scanned equipment

rigged on the WO

Activate setup of current WO

WO should be activated

Scan (PASS) PCB on upline

conveyor

PCB should be accepted by

machine

Set incorrect 1st character and

number of characters for print

medium in Maintenance\Machine

Setup\Barcodes. Open cover and

scan material

material verification should not be

possible due to wrong barcode

Disable print medium in Setup

Product\Option\Verification

no reaction on the printer

Activate recipe on iTAC with MES

key set to "OFF"

no reaction on the printer

Place PCB with no barcode on

upline conveyor

PCB should be accepted by

machine due to MES OFF in recipe

Activate previous recipe on iTAC

with MES key se to "ON"

no reaction on the printer

Change material barcode setting

back to original. Enable print

medium in Setup

Product\Option\Verification. Open

cover and scan material

All equipment and material should

be verified (green tick)

Scan (PASS) PCB on upline

conveyor

PCB should be accepted by

machine

Deactivate WO from iTAC, Scan

(PASS) PCB on upline conveyor

PCB should be rejected by machine

NOTES:

Issue 2, Mar 18

Glossary

ADM

ADMinistration module - The ADM Module is used to maintain

all master data such as machines/components/work

plans/equipment, etc.

API

Application Programming Interface module - API module is

basically the list of various functions (calls) which are used as

communication interface between machine (e.g. printer,

placement machine, etc.) and other software.

Assigned Serial

numbers

Are the barcodes for specific PCBs/panels assigned to the

specific work step - station. It can be found in TR\MIS - Work

orders\Order. Double click on blue icon of Order no. for

specific station, e.g. printer. Click on serial no. tab.

BOM

Bill Of Material module - is used for creating & editing of

BOMs.

Component side

Older terminology used by iTAC for PCB layer (usually Top

side/ 2

side).

Container number

Regarding paste printer it is the barcode on each individual

paste pot/cartridge/cassette, etc. It should contain unique

number.

Equipment

Equipment is each specific consumable which is necessary

for manufacturing of selected product on particular station (on

printer it is e.g. screen, squeegee, tooling, etc.).

ERP

Enterprise resource planning

Fail

Is the status of the PCB or panel inside of PCB (multipanel

PCB). The production failed, but panel can be repaired.

Material

Material is each physical part included in BOM. This means

final product contains this part which is used during

manufacturing process (on the printer it is only print material).

MDA

Manufacturing Data Administration module - We use this

module for administration of recipes only.

MES

Manufacturing Execution System

MES Switch

Is the recipe characteristic which determines whether the

MES is used or not. By default the MEASURE_NAME=MES

and NOMINAL=OFF

Material & Logistic module - maps material flow and logistics

for production lines – from receiving to finished goods

inventory. For DEK only print material is maintained in this

module. In this module can be found if the paste is rigged or

not.

Pass

Is the status of the PCB or panel inside of PCB (multipanel

PCB). The production passed and can be processed by next

work step

PCB

Printed Circuit Board

Recipe

The recipe is important for product name check – contains

program name for Top & Bottom side. Also contains MES

switch. MES switch determines whether station is using MES

or not.

Rigged material or

equipment

Material or equipment was verified and accepted by iTAC. If

any used material or equipment is not rigged the production

cannot start.

Issue 2, Mar 18

Scrap

Is the status of the PCB or panel inside of PCB (multipanel

PCB). The production failed and panel cannot be repaired.

Solder side

Older terminology used by iTAC for PCB layer (usually

Bottom side/ 1

side).

Traceability module - The TR Module can be used for tracing

of manufactured products, used components, etc. It is also

used for Work Order activation (TR\MIS - Work

Orders\Order).

Work order

Defines production order according to current demand. Work

order consists required quantity, Product part number + BOM

version and exact work plan version.

Work order is to be activated on the line in order to start

production.

Work Plan

Contains all work steps necessary for manufacturing of

specific product. Existing equipment can be assigned into

required work step (e.g. paste printer) of selected Work plan

version.
