104 2020/2021 IEC EN IEC EN AEROST A T ® PC – PORT ABLE BENCHTOP IONIZER • Compact and portable, quickly neutralizes static charges • Effective ar ea 30 x 150 cm • Unique point cleaner • V ariable speed fan with integrat…

103

2020/2021

IEC

7100.WIM47.SB

AIR IONIZER, IONIZER MONITOR

IONIZER MONITOR – WIM 47

The WIM 47 is a handheld monitoring device for the fully automatic

checking of ionizers at the ESD workstation or in machines.

It measures the positive and negative discharges as well as the

offset voltages.

An alarm is signaled acoustically and optically.

In case of an error a switching output can switch off the Ioniser or

report the alarm to a higher-level controller, e. g. by using the

switch box 7100.WIM47.SB.

• Size: 70 x 70 x 85 mm (W x D x H)

• Weight: 300 g

• Includes:

1 x Ionizer Monitor WIM 47

1 x Power supply with adapter (EU/USA)

1 x ground cord

1 x operating instructions

Optional:

Switch Box, which controls the

Voltage supply for the connected ionizer via a relay contact.

Part Nr.

7100.WIM47 Ionizer Monitor WIM 47

7100.WIM47.SB SwitchBox (optional) for German sockets

• Compact and portable, quickly neutralizes static charges

• Effective area up to 120 cm

• Unique emitter point cleaner

• Fan speed control “Low”, “Medium and “High”

with integrated heater

• Ionization indicator

• Inherently balanced to ± 10 V (micropulse AC ionization)

• AC technology, Ozone generation: 0,05 ppm,

measured 30 cm in front of the unit

Size: 173 x 231 x 84 mm (W x H x D)

Part Nr.

7500.PC2.H Portable Ionizer

AEROSTAT

PC2 – PORTABLE IONIZER

application example

Video

104

2020/2021

IEC

AEROSTAT

PC – PORTABLE BENCHTOP IONIZER

• Compact and portable, quickly neutralizes static charges

• Effective area 30 x 150 cm

• Unique point cleaner

• Variable speed fan with integrated heater

• Ionization indicator

• Inherently balanced to ± 10 V

• AC technology, Ozone generation: 0,005 ppm, measured 15 cm

in front of the unit

Size: 140 x 219 x 83 mm (W x H x D)

Part Nr. Qty.

7500.PC Portable Ionizer

7500.G.FR Frame

7500.G.F Filter 6 pieces

Accessories

AIR IONIZERS

ENDSTAT

2020 – PORTABLE BENCHTOP IONIZER

• Compact and portable, quickly neutralizes static charges

• Effective area 30 x 150 cm

• Unique point cleaner

• Integrated 2 speed fan

• Inherently balanced to ± 15 V

• AC technology, Ozone generation: 0,01 ppm,

measured 15 cm in front of the unit

Size: 145 x 210 x 95 mm (W x H x D)

Part Nr.

7500.ES2020 Portable Ionizer

105

2020/2021

IEC

AIR IONIZERS

5802 – PORTABLE BENCHTOP IONIZER

• Compact and portable, quickly neutralizes static charges

• Effective area 30 x 150 cm

• Automatic emitter point cleaner

• 2 step speed fan

• Ionization indicator

• Inherently balanced to ± 3 V

• DC technology (Steady State DC)

• Ozone generation: 0,008 ppm

• Suitable for cleanroom class 4, ISO 14644

Size: 193 x 267 x 127 mm (W x H x D)

Part Nr.

7500.5802.CXL.E Portable Ionizer

SMB60 – PORTABLE BENCHTOP IONIZER

• Quickly neutralizes static charges at work station or service areas

• Ionization area: 300 x 900 mm

• Integrated fan with variable speed

• High frequency, AC ionisation (HF-AC)

• Compact Piezoceramic high voltage transformer

• Power supply 24 VDC / 100-240 VAC with wall

mounting transformer (included)

• Self balancing ± 20 V

• Replaceable air filter

• Alarm output

• Ozone generation 0,005 ppm, measured 15 cm in front of the

unit

Size: 153 mm x 99 mm x 65 mm (W x H x D)

Part Nr.

7520.HF.SMB60 Portable Ionizer

7520.HF.SMB60.F Filter

Filter change

illustration
