110 2020/2021 IEC EN 7520.SIB3.SBP .RD 7520.SIB3.NT 7520.SIB3.XXX.RD AERO-BODY ION BAR SIB3 RD Part Nr . Aero-Body Ion Bar SIB3RD 7520.SIB3.600.RD 660 mm, 13 emitters 7520.SIB3.700.RD 852 mm, 15 emitters 7520.SIB3.800.RD…
109
2020/2021
IEC
EN
IEC
EN
AIR IONIZERS
• Neutralization of electrostatic charges at work areas
• Effective area 60 x 90 cm
• Automatic emitter point cleaner
• 2 step speed fans
• Steady-state DC Technology
• Inherently balanced to ± 3 V
• Ozone generation: 0,02 ppm
• Suitable for cleanroom class 4, ISO 14644
Part Nr. Model Dimensions (W x H x D)
7500.5810.C32X.E 2 fans 810 x 100 x 170 mm
FUSION
TM
Mini Ionizer for applications with space constraint and low clearance
• Ideal for pick and place machines and wave soldering
• Integrated controller
• Self-balancing
• Steady State DC operation
• Up to 4 units can be interconnected
• Optional fan support
• Emitter points: tungsten
Dimensions: 115 x 33 x 31 mm (L x W x H)
Part Nr.
7500.FU Fusion
TM
– Mini Ionizer
7500.FU.T Fusion
TM
– Power supply 230V AC / 24V DC for up to 4 ionizers
7500.FU.F Fusion
TM
– Optional fan assembly 44 x 44 x 50 mm (L x W x H)
application example
5810 – OVERHEAD IONIZER
110
2020/2021
IEC
EN
7520.SIB3.SBP.RD
7520.SIB3.NT
7520.SIB3.XXX.RD
AERO-BODY ION BAR SIB3 RD
Part Nr.
Aero-Body Ion Bar SIB3RD
7520.SIB3.600.RD 660 mm, 13 emitters
7520.SIB3.700.RD 852 mm, 15 emitters
7520.SIB3.800.RD 962 mm, 17 emitters
7520.SIB3.900.RD 1017 mm, 18 emitters
7520.SIB3.1000.RD 1127 mm, 20 emitters
7520.SIB3.1200.RD 1292 mm, 23 emitters
7520.SIB3.1300.RD 1457 mm, 26 emitters
7520.SIB3.1500.RD 1567 mm, 28 emitters
7520.SIB3.1600.RD 1677 mm, 30 emitters
7520.SIB3.1800.RD 1897 mm, 34 emitters
7520.SIB3.2100.RD 2227 mm, 40 emitters
7520.SIB3.2200.RD 2337 mm, 42 emitters
7520.SIB3.2300.RD 2447 mm, 44 emitters
7520.SIB3.2500.RD 2667 mm, 48 emitters
7520.SIB3.3000.RD 3107 mm, 56 emitters
7520.SIB3.3200.RD 3272 mm, 59 emitters
Accessories
7520.SIB3.SBP.RD Power Supply 230 V AC / 24 V DC
for Aero-Body Ion Bar SIB3 RD
7520.SIB3.NT Universal power supply for one SIB3
230 V AC / 24 V DC
Ionizing bar:
• Suitable for down-stream applications i.e. „laminar airflow boxes“
• Air assistance for various applications
• Pulsed AC high voltage Ionization
• Each tip emits positive and negative ions
• Remote controller for adjustments of pulse frequency and duty
cycle
• Self-balancing ± 30V
• Control input and alarm output connector
• 24V power supply
• Easy emitter replacement
• Includes:
Ion bar without power supply
Remote control
10 m power cable with RJ45 plug
10 m signal cable with RJ45 plug
Power Supply for Aero-Body Ion Bar SIB3RD:
• power supply of 24V/DC for max. 4 bars
AIR IONIZERS
111
2020/2021
IEC
EN
7520.SIB3.SBP.2R
7520.SIB3.250.RD
7520.SIB3.330.RD
AERO-BODY ION BAR SIB3 RD + CONTROLLER
AIR IONIZERS
Part Nr.
Aero-Body Ion Bar SIB3 RD
7520.SIB3.250.RD 377 mm, 5 emitters
7520.SIB3.330.RD 457 mm, 6 emitters
Accessories
7520.SIB3.SBP.2R Controller for SIB3-250 RD/330 RD
• Suitable for down-stream applications i.e. „laminar airflow boxes“
• Air assistance for various applications
• Pulsed AC high voltage Ionization
• Each tip emits positive and negative ions
• Self-balancing ± 30V
• Control input and alarm output connector
• Power supply 230V/AC via controller
• One controller is suitable for two ion bars
• Adjustments on controller side
• Easy emitter replacement
Controller for SIB3-250 RD/330 RD
• For up to 2 ion bars
• Set-up of bar is done via controller
• Power supply 24V/DC via controller
