74 2020/2021 GROUNDING ACCESSORIES • Grounding box with 7 scr ews • Suitable for 4 mm ring terminal connection • Reliable grounding cor ds connection to ESD ground or protective ground • Removable protection lid • ESD sy…
73
2020/2021
7100.181
7100.181.H
7100.181.K
7100.181.K.M
7100.181.C
SAFETY PIPS
Continuous wrist strap monitor
Test method: Impedance capacitive measurement
Test range: 1 MOhm ...(100 pF + 2 MOhm) OK
HI-Fail > 5 Mohm
LO-Fail < 400 kohm
Signal: Audible and visible (7100.181)
+ visible and via relay output (7100.181.K)
Part Nr.
7100.181 Safety Pips with a 10 mm snap (battery operated)
incl. calibration certifi cate
7100.181.K Safety Pips with relay output, 10 mm snap
Operation: 230 VAC power supply
incl. calibration certifi cate
7100.181.C Calibration Unit for Safety Pips / Safety Pips K
incl. calibration certifi cate
7100.181.103 Power supply 230V AC for 7100.181 retrofi t
7100.181.H Mounting bracket for Safety Pips
7100.181.K.M Additional module with 3 LED’s (two colours: red and green),
for Safety Pips K with about 2 m connecting cable
application example
GROUNDING ACCESSORIES
Video
74
2020/2021
GROUNDING ACCESSORIES
• Grounding box with 7 screws
• Suitable for 4 mm ring terminal connection
• Reliable grounding cords connection to ESD ground or protective
ground
• Removable protection lid
• ESD symbol
Part Nr.
2200.B Central grounding box
Stackable banana plug socket/10 mm, 1 Mohm
resistorized snap, a 3 m cord and a banana plug.
Part Nr. Length Connection
2250.757 3 m 10 mm encapsulated snap /
banana plug socket
• Grounding Cord with protective cap
• 1 Mohm safety resistor
Part Nr. Length Connection
2250.790 1,8 m 10 mm snap/4 mm ring terminal
for table mats
2250.790.2 4,5 m 10 mm snap/4 mm ring terminal
for fl oor mats
• For floor and table mats with 1 Mohm safety resistor
Part Nr. Length Connection
2250.758.1 0,75 m 10 mm snap/4 mm ring terminal
2250.758 1,5 m 10 mm snap/4 mm ring terminal
2250.758.2 3,0 m 10 mm snap/4 mm ring terminal
2250.756 1,5 m 10 mm snap/banana plug
2250.765 3,0 m 10 mm snap/banana plug
2250.762 1,5 m 10 mm snap/10 mm snap
2250.762.1 1,5 m 10 mm snap/10 mm snap without resistor
CENTRAL GROUNDING BOXGROUNDING CORD
GROUNDING CORDGROUNDING CORD
underneath
75
2020/2021
2200.121.10.1
2200.121.10
2200.121.10.2
2200.W.3
2200.121.10.13
2200.W.5
2200.110.Y
2201.258 2201.2452201.230
2200.113.Y2200.111.Y
2200.115.Y
GROUNDING ACCESSORIES
EARTH CONNECTING BOX
Earth Bonding Point (EBP) includes 2,0 m earthing cable
with a 4 mm ring terminal (1 Mohm resistor for every input).
Part Nr.
2200.121.10 2 x 10 mm snaps and 1 x 4 mm; banana plug socket
2200.121.10.1 With 3 x 10 mm snaps
2200.121.10.2 ith 1 x 10 mm snap and 2 x 4 mm banana plug sockets
2200.W.3 Yellow, right angle with 3 x 10 mm snaps
2200.121.10.13 2 x plug socket for 3M system; 1 x 10 mm snap
2200.W.5 1 x 10 mm snap; 2 x 4 mm banana plug socket
GROUNDING PLUG
Used for direct and easy mat grounding
Part Nr.
2200.110.Y Without cable, banana plug socket, without resistor
2200.111.Y With 2,4 m coil cord, 1 Mohm safety resistor and a 10 mm snap
2200.113.Y 2 m fl at cable, 4 mm ring terminal, without resistor
2200.115.Y With 4,5 m fl at cable, 1 Mohm safety resistor and a 10 mm snap (with protective cap)
2201.230 Without cable, 1 MOhm resistor; 3 x 10 mm snap
2201.245 Without cable, 1 MOhm resistor; 2 x 10 mm snap, 1 x screwed connection for 4 mm ring terminal
2201.258 Without cable, 1 MOhm resistor; 1 x 10 mm snap, 2 x 4 mm banana plug socket
